Wago 859-722
Optocoupler module; Nominal input voltage: 110 VDC; Output voltage range 12 …30VDC; Limiting continuous current: 50 mA; 2-wire connection; Railway; Red status indicator; Module width: 6 mm; gray 859…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Optocoupler module; Nominal input voltage: 110 VDC; Output voltage range 12 …30VDC; Limiting continuous current: 50 mA; 2-wire connection; Railway; Red status indicator; Module width: 6 mm; gray 859-722
Specification
Notes
| Note | Optocouplers and solid state relays are designed for use in signal processing networks that are not supplied directly by the low-voltage power supply network. |
|---|
Technical data - Control circuit
| Nominal input voltage U<sub>N</sub> | 110 VDC |
|---|---|
| Input voltage range (low level) | 0 … 20 VDC |
| Input voltage range (high level) | 77 … 137.5 VDC |
| Nominal input current at U<sub>N</sub> | 3 mA |
Technical data - Load circuit
| Circuit type | 2-wire connection |
|---|---|
| Limiting continuous current | 0.05 A |
| Nominal output voltage | 24 VDC |
| Output voltage range | 12 … 30 VDC |
| Voltage drop | ≤ 2 VDC |
| Leakage current at rated voltage | ≤ 25 µA |
| Turn-on time | ≤ 20 µs |
| Turn-off time | ≤ 120 µs |
| Switching frequency | ≤ 1.5 kHz |
Technical data - Signaling
| Status indicator | Red LED |
|---|
Safety and protection
| Rated voltage | 300 V |
|---|---|
| Type of circuits | Mains circuits |
| Overvoltage category | II |
| Pollution degree | 2 |
| Dielectric strength (control/load circuit) (AC, 1Â min) | 3 kVrms |
| Insulation type (control/load circuit) | Reinforced insulation (safe isolation) |
| Insulation type (adjacent devices) | Reinforced insulation (safe isolation) |
| Insulation type (between adjacent devices of the same type) | Reinforced insulation (safe isolation) |
| Insulation type (to adjacent devices of different types) | Basic insulation |
| Protection type | IP20; in connected state or when using 859-525 end plate |
Connection data
| Connection technology | CAGE CLAMP® |
|---|---|
| Solid conductor | 0.08 … 2.5 mm² / 28 … 14 AWG |
| Fine-stranded conductor | 0.08 … 2.5 mm² / 28 … 14 AWG |
| Fine-stranded conductor; with insulated ferrule | 0.08 … 1.5 mm² / 28 … 16 AWG |
| Strip length | 5 … 6 mm / 0.2 … 0.24 inches |
Physical data
| Width | 6 mm / 0.236 inches |
|---|---|
| Height | 91 mm / 3.583 inches |
| Depth from upper-edge of DIN-rail | 56 mm / 2.205 inches |
Mechanical data
| Mounting type | DIN-35 rail |
|---|---|
| Mounting position | horizontal (standing/lying); vertical |
Material data
| Note (material data) | Information on material specifications can be found here |
|---|---|
| Color | gray |
| Insulation material (main housing) | Polyamide (PA66) |
| Material group | I |
| Flammability class per UL94 | V0 |
| Fire load | 0.313 MJ |
| Weight | 18.3 g |
Environmental requirements
| Ambient temperature (operation at U<sub>N</sub>) | -40 … +70 °C |
|---|---|
| Ambient temperature (storage) | -40 … +70 °C |
| Processing temperature | -25 … +50 °C |
| Temperature range of connection cable | ≥ (Tambient + 20 K) |
| Relative humidity | 5 … 95 % (no condensation permissible) |
| Operating altitude (max.) | 2000 m |
Standards and specifications
| Standards/specifications | EN 61010-2-201, EN 61000-6-2, EN 61000-6-3, EN 50121-3-2 |
|---|
Commercial data
| Product Group | 6 (INTERFACE ELECTRONIC) |
|---|---|
| PU (SPU) | 1 pcs |
| Packaging type | Box |
| Country of origin | DE |
| GTIN | 4066966181883 |
| Customs tariff number | 85365005000 |
Product Classification
| UNSPSC | 32101517 |
|---|---|
| eCl@ss 10.0 | 27-26-15-03 |
| eCl@ss 9.0 | 27-26-15-03 |
| ETIM 9.0 | EC001504 |
| ETIM 10.0 | EC001504 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| CAS-No. | 7439-92-1, 79-94-7 |
|---|---|
| REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol, Lead |
| RoHS Compliance Status | Compliant,With Exemption |
| RoHS Exemption | 7(a) |
| SCIP notification number (Austria) | dfe1a7d2-46c3-4d04-bf7a-4858403092f5 |
| SCIP notification number (Belgium) | f43dc37c-bdb5-4588-b72f-4306f91941b4 |
| SCIP notification number (Bulgaria) | f19c7c25-c6e0-4ab5-aae5-db993d266f19 |
| SCIP notification number (Czech Republic) | da301c04-9d3d-4478-8d7a-e3f9c5c6bc85 |
| SCIP notification number (Denmark) | 34f0dda5-2fd0-4fc4-b12c-d65b9b7e51c7 |
| SCIP notification number (Finland) | 64740d19-2f2a-4f26-91b3-9280c978c794 |
| SCIP notification number (France) | 91974923-8418-48b0-b0a8-1d0533551dc3 |
| SCIP notification number (Germany) | ace42152-917e-487e-8ff2-72adb1344ae7 |
| SCIP notification number (Hungary) | c1343e58-9756-4347-9198-0b6419497f9b |
| SCIP notification number (Italy) | f44d140b-ae40-49bc-9be4-f06151455832 |
| SCIP notification number (Netherlands) | 55c35486-71b3-4589-ba95-f658d975343b |
| SCIP notification number (Poland) | 56e2c9b1-d3e7-46ea-b859-a513abd99dc1 |
| SCIP notification number (Romania) | ed33b97c-9e70-4800-9cd2-06e7f46aecf7 |
| SCIP notification number (Sweden) | de616fd9-5afb-4b92-ada0-a580fb1d138f |
