Wago 286-891
Component module with fuse; for (5 x 20) mm microfuse; Nominal voltage: 230 VAC/DC; gray 286-891
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Component module with fuse; for (5 x 20) mm microfuse; Nominal voltage: 230 VAC/DC; gray 286-891
Specification
Electrical data
| Nominal operating voltage | 230 VAC/VDC |
|---|---|
| Fuse capacity (max.) | 6.3 A |
| Leakage current in case of a blown fuse | 0.5 mA |
Safety and protection
| Rated voltage | 250 V |
|---|---|
| Rated impulse withstand voltage | 4 kV |
| Pollution degree | 3 |
Physical data
| Width | 10 mm / 0.394 inches |
|---|---|
| Height | 52 mm / 2.047 inches |
| Depth from upper-edge of DIN-rail | 82.5 mm / 3.346 inches |
| Note (dimensions) | Depth including carrier terminal block |
Mechanical data
| Mounting type | Pluggable module for receptacle terminal blocks |
|---|---|
| Housing design | Plug for carrier terminal blocks |
Material data
| Color | gray |
|---|---|
| Fire load | 0.263 MJ |
| Weight | 14.1 g |
Environmental requirements
| Ambient temperature (operation) | -25 … +40 °C |
|---|---|
| Relative humidity | 5 … 95 % (no condensation permissible) |
| Operating altitude (max.) | 2000 m |
Commercial data
| Product Group | 6 (INTERFACE ELECTRONIC) |
|---|---|
| PU (SPU) | 30 (1) pcs |
| Packaging type | box |
| Country of origin | DE |
| GTIN | 4045454376482 |
| Customs tariff number | 85363010000 |
Product Classification
| UNSPSC | 39121624 |
|---|---|
| eCl@ss 10.0 | 27-14-11-16 |
| eCl@ss 9.0 | 27-14-11-16 |
| ETIM 9.0 | EC000899 |
| ETIM 10.0 | EC000899 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,No Exemption |
|---|
