Wago 788-148
Filter module; RC filter element; Nominal voltage: 230 VAC 788-148
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Filter module; RC filter element; Nominal voltage: 230 VAC 788-148
Specification
Notes
| Note | To guarantee safe operation, residual voltages (due to the cable capacitance of long connection lines or leakage currents of semi-conductor switches and their protective circuits) must be lower than the release voltage of the relays.For DC relays, the release voltage is specified with ≤ 5% of the nominal voltage; for AC relays, it is 15% of the nominal voltage (per VDE 0435).The relay may not reset if a high residual voltage exists. Depending on the reason for the residual voltage, changing the cable routing or a parallel connection of an RC element could remedy this situation. |
|---|
Technical data - Control circuit
| Nominal input current at U<sub>N</sub> | 0 |
|---|
Technical data - Operating data
| Nominal operating voltage | 230 VAC |
|---|---|
| Operating voltage | 0 … 230 VAC |
| Current consumption at U<sub>N</sub> | 7.2 mA (230 VAC; 50 Hz); 3.6 mA (115 VAC; 50 Hz) |
| Nominal mains frequency range | 50 … 60 Hz |
Technical data - Module characteristics
| Resistor | 470 Ω |
|---|---|
| Capacitance | 100 nF |
Safety and protection
| Protection type | IP20 |
|---|
Physical data
| Width | 15 mm / 0.591 inches |
|---|---|
| Height from the surface | 15.7 mm / 0.618 inches |
| Depth | 10 mm / 0.394 inches |
Mechanical data
| Mounting type | Pluggable module |
|---|
Material data
| Note (material data) | Information on material specifications can be found here |
|---|---|
| Fire load | 0.027 MJ |
| Weight | 1.5 g |
Environmental requirements
| Ambient temperature (operation at U<sub>N</sub>) | -25 … +70 °C |
|---|---|
| Ambient temperature (storage) | -40 … +70 °C |
Standards and specifications
| Standards/specifications | EN 60664-1 |
|---|
Commercial data
| Product Group | 6 (INTERFACE ELECTRONIC) |
|---|---|
| PU (SPU) | 50 (25) pcs |
| Packaging type | box |
| Country of origin | DE |
| GTIN | 4050821583547 |
| Customs tariff number | 85369010000 |
Product Classification
| UNSPSC | 39121610 |
|---|---|
| eCl@ss 10.0 | 27-37-16-01 |
| eCl@ss 9.0 | 27-37-16-92 |
| ETIM 9.0 | EC002586 |
| ETIM 10.0 | EC002586 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,No Exemption |
|---|
