Wago 283-908
Shield terminal block, 283 Series, whiteOur shield terminal block (item number 283-908) is designed for seamless electrical installations. Strip lengths must be between 16 and 17 mm when connecting c…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Shield terminal block, 283 Series, whiteOur shield terminal block (item number 283-908) is designed for seamless electrical installations. Strip lengths must be between 16 and 17 mm when connecting conductors to this shield terminal block. By connecting to the mounting rail via an integrated contact foot, shield terminal blocks provide a reliable electrical and mechanical connection between electrical conductors and the mounting adapter. This allows them to suppress interference signals and ensure high signal quality. This product features conductor terminals and utilizes CAGE CLAMP®. Our highly-rated and maintenance-free CAGE CLAMP® connection makes it easy to connect all conductor types without having to prepare the conductor. For example, you don’t need to crimp ferrules. This shield terminal block is suitable for conductor cross sections ranging from 0.2 mm² to 16 mm².An operating tool is used to operate this through rail-mount terminal block.
Specification
Electrical data - Ratings per IEC/EN
| Ratings per | IEC/EN 60947-7-2 |
|---|---|
| Nominal voltage (III/3) | 800 V |
| Rated impulse withstand voltage (III / 3) | 8 kV |
| Rated current | 76 A |
| Ratings per | IEC/EN 60947-7-2 / IEC/EN 60947-7-2 / IEC/EN 60947-7-2 |
| Overvoltage category | III / III / II |
| Pollution degree | 3 / 2 / 2 |
| Nominal voltage | 800 V |
| Rated impulse withstand voltage | 8 kV |
| Rated current | 76 A |
Electrical data - General information
| Wiring direction | Front-entry wiring |
|---|
Connection data
| Clamping units | 2 |
|---|---|
| Total number of potentials | 1 |
| Number of levels | 1 |
Connection data - Connection 1
| Connection technology | CAGE CLAMP® |
|---|---|
| Actuation type | Operating tool |
| Connectable conductor materials | Copper |
| Solid conductor | 0.2 … 16 mm² / 24 … 6 AWG |
| Fine-stranded conductor | 0.2 … 16 mm² / 24 … 6 AWG |
| Strip length | 16 … 17 mm / 0.63 … 0.67 inches |
| Wiring direction | Front-entry wiring |
Physical data
| Width | 12 mm / 0.472 inches |
|---|---|
| Height | 94.5 mm / 3.72 inches |
| Depth from upper-edge of DIN-rail | 37.5 mm / 1.476 inches |
Mechanical data
| Design | horizontal type |
|---|---|
| Mounting type | DIN-35 rail |
| Marking level | Center marking |
Material data
| Note (material data) | Information on material specifications can be found here |
|---|---|
| Color | white |
| Material group | I |
| Insulation material (main housing) | Polyamide (PA66) |
| Flammability class per UL94 | V0 |
| Fire load | 0.502 MJ |
| Weight | 46.6 g |
Environmental requirements
| Processing temperature | -35 … +85 °C |
|---|---|
| Continuous operating temperature | -60 … +105 °C |
Commercial data
| PU (SPU) | 20 pcs |
|---|---|
| Packaging type | box |
| Country of origin | DE |
| GTIN | 4045454084578 |
| Customs tariff number | 85369010000 |
Product Classification
| UNSPSC | 39121410 |
|---|---|
| eCl@ss 10.0 | 27-14-11-41 |
| eCl@ss 9.0 | 27-14-11-41 |
| ETIM 9.0 | EC000901 |
| ETIM 10.0 | EC000901 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| CAS-No. | 7439-92-1 |
|---|---|
| REACH Candidate List Substance | Lead |
| RoHS Compliance Status | Compliant,No Exemption |
| SCIP notification number (Austria) | 44919da6-0591-49c4-b8b9-ce87ca1d0dc0 |
| SCIP notification number (Belgium) | 53afe1c4-73dd-430d-bc53-25e3fe6b1250 |
| SCIP notification number (Bulgaria) | 1237d60c-cd01-4fe9-bb59-e4a5a26ed823 |
| SCIP notification number (Czech Republic) | eeb300ec-13db-46f8-980e-cf44ae712e63 |
| SCIP notification number (Denmark) | c7300ac4-07ce-4683-9819-45486d0d9bce |
| SCIP notification number (Finland) | ca337ce1-e3ce-41da-85c7-6d0eae928390 |
| SCIP notification number (France) | 71628dd8-98c6-4bdb-ab5d-084a47a4be2b |
| SCIP notification number (Germany) | 1c305480-dc62-4a36-8fd8-b02cb4823fcb |
| SCIP notification number (Hungary) | 500d2b02-7e04-4bd2-a2f6-197e8a4c3224 |
| SCIP notification number (Italy) | 770fbe62-8990-4371-8d99-18f810360895 |
| SCIP notification number (Netherlands) | 76534a4e-7ad5-42f4-9342-6d897881fa4b |
| SCIP notification number (Poland) | 47bc7aa3-4293-420e-962b-6328b9fd32fa |
| SCIP notification number (Romania) | fe94fc76-ad23-4338-8caa-e1db7d3daccf |
| SCIP notification number (Sweden) | 10401bb6-36fc-4497-b0e3-6f3f91df60c3 |
