Wago 2606-1102/020-016

PCB terminal block, 2606 Series, green-yellowOur PCB terminal block (item number 2606-1102/020-016) is designed for seamless electrical installations. It is a universal connector that can be used almost anywhere, e.g., as a pluggable PCB connector, panel feedthrough header, connector for rail-mount terminal blocks, or a floating connector for different mounting methods. Our PCB terminal block is rated for 1000 V and is designed to handle a rated current of up to 41 A. It can therefore be used in high-load applications. Conductors should only be connected to this PCB terminal block if their strip length is between 11 mm and 13 mm. Featuring one conductor terminal along with Push-in CAGE CLAMP®, this product delivers reliable performance. Our Push-in CAGE CLAMP® is a universal, maintenance-free connection solution for all conductor types, featuring a winning design: It allows direct insertion of both solid and fine-stranded conductors with ferrules without needing tools. No preparation is required; for example, crimping the conductor’s ferrule is not necessary. The item’s dimensions are 17.85 x 28 x 24.3 mm (width x height x depth). Depending on the conductor type, this PCB terminal block is designed for conductor cross sections ranging from 0.2 mm² to 10 mm². It has one level. Two potentials can connect using the two clamping points The contacts are made of electrolytic copper (ECu), the green-yellow housing is made of polyamide (PA66) for insulation, and the clamping spring is made of chrome-nickel spring steel (CrNi). The contact surface is coated with tin. A lever is used to operate this PCB terminal block. THT is used to assemble the PCB terminal block. The conductor is designed to be inserted into the board at an angle of 0°.. The solder pins are organized over the entire terminal strip (staggered) and are 1.5 x 1.2 mm cross-section and 4 mm in length. Each potential has one solder pin.
