Danfoss (Drives) 15612N-32-32Z
HOSE NIPPLE ASSY,2P/32,NPTF-M/32,CS,STR – 15612N-32-32Z
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
HOSE NIPPLE ASSY,2P/32,NPTF-M/32,CS,STR – 15612N-32-32Z
Specification
| A Dimension In | 5.190 |
|---|---|
| A Dimension Mm | 132.000 |
| Angle Shape | Straight |
| Application | General industrial use, Hydraulic systems, Petroleum based fluids, Water based fluids |
| Brand | Winner by Danfoss |
| Compatible Hose Id In | 2.000 |
| Compatible Hose Id Mm | 50.800 |
| Construction Style | Crimp |
| End Size 1 | -32 |
| End Type 1 | Male pipe (NPTF) |
| End Type 2 | Line/hose/tube |
| Finish Plating | Zinc plating |
| Hex Size 1 In | 2.559 |
| Hex Size 1 Mm | 65.000 |
| Hose Cut Off Factor In | 2.330 |
| Hose Cut Off Factor Mm | 59.400 |
| Hose Size | -32 |
| Inside Diameter In | 1.6600 |
| Inside Diameter Mm | 42.2000 |
| Product Height In | 2.952 |
| Product Height Mm | 75.000 |
| Product Length In | 5.196 |
| Product Length Mm | 132.000 |
| Product Material | Carbon steel |
| Product Width In | 2.559 |
| Product Width Mm | 65.000 mm |
| Series | Winner 2-Piece |
| Thread Sealant | No |
| Thread Size 1 | 1 1/2-11 1/2 NPT |
