Danfoss (Drives) 123AL00044B
PVM131MR11GS2C315200001AB-CA00, PVM131MR11GS2C315200001AB-CA00 – 123AL00044B
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
PVM131MR11GS2C315200001AB-CA00, PVM131MR11GS2C315200001AB-CA00 – 123AL00044B
Specification
| Code Title | VARIABLE DISPLACEMENT OPEN CIRCUIT PISTON PUMPS |
|---|---|
| D I S P L A C E M E N T | 131.1 cm3/r [8.00 in3/r] (315 bar MAX) |
| Valve Plate | HIGH SPEEDS VERSION |
| Input Rotation | CLOCKWISE (RIGHTHAND) |
| Input Shaft | SAE J744-32-4, SAE C, 14T SPLINE (MODEL 057 074,098 AND 131) |
| Mounting Flange | SAE J744-127-4 (C 4-BOLT)(MODELS 057,074,098 AND 131) |
| Main Port Location | SIDE |
| Port Options | SAE J518 FLANGE PORTS, SAE AUXILIARY PORTS |
| C O N T R O L | PRESSURE AND FLOW COMPENSATOR WITH PLUGGED ORIFICE |
| Pressure Comp Setting | 315 bar [4567 lbf/in2][DEFAULT] |
| Flow Comp Setting | 20±1 bar [290±14.5 lbf/in2][DEFAULT] |
| Power Control Setting | NONE |
| Auxiliary Mounting | AUXILIARY A-MOUNT WITH COVER PLATE AND NO COUPLER |
| Paint | BLACK [DEFAULT] |
| Design Code | B |
| D I F F E R E N T I A T O R | – |
| Pump Special Features | ADJUSTABLE MAX DISPLACEMENT STOP (CONTAINS SINGLE SHAFT SEAL) DESTROKE TO 106.5 CM3/R [6.50 IN3/R] |
| Compensator Special Features | NONE |
| Customer Identification | NONE |
| Ipm Frame Size | PVM Code B 131cc Pump |
| Model Code 1 | PVM131MR11GS2C315200001AB-CA00 |
| Proposition 65 | Cancer and Reproductive Harm |
