Danfoss (Drives) 12212Y-20-20Z
HOSE NIPPLE ASSY,1P/20,BSPP-M/20,CS,STR – 12212Y-20-20Z
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
HOSE NIPPLE ASSY,1P/20,BSPP-M/20,CS,STR – 12212Y-20-20Z
Specification
| A Dimension In | 3.937 |
|---|---|
| A Dimension Mm | 100.000 |
| Angle Shape | Straight |
| Brand | Winner by Danfoss |
| Compatible Hose Id In | 1.250 |
| Compatible Hose Id Mm | 31.800 |
| Construction Style | Crimp |
| End Type 1 | Male ORB BSPP |
| Finish Plating | Zinc plating |
| Hex Size 1 In | 1.960 |
| Hex Size 1 Mm | 49.784 |
| Hose Cut Off Factor In | 1.811 |
| Hose Cut Off Factor Mm | 46.000 |
| Hose Size | -20 |
| Inside Diameter In | 1.0620 |
| Inside Diameter Mm | 27.0000 |
| Product Height In | 2.260 |
| Product Height Mm | 57.404 |
| Product Length In | 1.810 |
| Product Length Mm | 45.974 |
| Product Material | Carbon steel |
| Product Width In | 1.960 |
| Product Width Mm | 49.784 mm |
| Thread Sealant | No |
| Thread Size 1 | G 1 1/4 |
| Working Temperature Max C | 100 |
| Working Temperature Max F | 212 |
| Working Temperature Min C | -40 |
| Working Temperature Min F | -40 |
