Danfoss (Drives) 1219-130E4
BLK-5/32 OD.FRPE/TBG-GRNin – 1219-130E4
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
BLK-5/32 OD.FRPE/TBG-GRNin – 1219-130E4
Specification
| E A N/ U P C | 813688029283 |
|---|---|
| Bend Radius Min (Inch) | 0.510 |
| Bend Radius Min (Mm) | 12.954 |
| Brand | Synflex by Danfoss |
| Color | Green stripe |
| Compliances | UL 94V2 |
| Construction | Extruded |
| Inside Diameter (Inch) | 0.10 |
| Inside Diameter (Mm) | 2.54 |
| Outside Diameter (Inch) | 0.16 |
| Outside Diameter (Mm) | 4.06 |
| Reinforcement Material | Polyethylene |
| Series | 1219 Series |
| Tube Material | Polyethylene (PE) |
| Tube Wall Thickness (Inch) | 0.03 |
| Tube Wall Thickness (Mm) | 0.76 |
| Working Pressure Max (Bar) | 3 |
| Working Pressure Max (Psi) | 48 |
| Working Temperature Max (C) | 80 |
| Working Temperature Max (F) | 176.0 |
| Working Temperature Min (C) | -40 |
| Working Temperature Min (F) | -40.0 |
