Danfoss (Drives) 10H41143
COUPLING,HK,F,1″1/4,CS,-20NPTF,FKM – 10H41143
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
COUPLING,HK,F,1″1/4,CS,-20NPTF,FKM – 10H41143
Specification
| E A N/ U P C | 678146159441 |
|---|---|
| Air Inclusion Max Cc | 48.00 |
| Air Inclusion Max In3 | 2.93 |
| Angle Shape | Straight |
| Application | Aerospace, Agriculture, Chemical, Construction, Consumer products, Fluid transfer, Food and beverage, General industry, Hvac, Hydraulics, Law enforcement/rescue, Medical, Military, Oil and gas, Transportation, Trucks |
| Body Size | 1 1/4″ |
| Brand | Danfoss |
| Certifications | ISO 7241-1 Series B |
| Connection Style | Manual connect |
| End Size 1 | -20 |
| End Size 2 | -20 |
| End Type 1 | Female Push to Connect |
| End Type 2 | Female pipe (NPTF) |
| Finish Plating | Zinc |
| Flow Rate Gpm | 76.00 |
| Flow Rate Lpm | 287.69 |
| Fluid Loss Cc | 48.00000 |
| Fluid Loss In3 | 2.92900 |
| Hex Size 1 In | 2.380 |
| Hex Size 1 Mm | 60.452 |
| Item Type | Female half |
| Latch Type | Push/pull |
| Product Length In | 4.510 |
| Product Material | Carbon steel |
| Safety Locking Mechanism | Sleeve lock |
| Seal Material | Fluorocarbon (FKM) |
| Sub Brand | Hansen |
| Thread Size 1 | 1 1/4-11 1/2 NPTF |
| Valve Type | 2 way |
| Working Pressure Max Psi | 2900 |
| Working Pressure Max Bar | 200 |
| Working Temperature Max C | 204 |
| Working Temperature Max F | 400 |
| Working Temperature Min C | -26 |
| Working Temperature Min F | -15 |
