Danfoss (Drives) 10510B-106-BG
HOSE INSERT ASSY,B1/10,NPTF-M/06,B,STR – 10510B-106-BG
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
HOSE INSERT ASSY,B1/10,NPTF-M/06,B,STR – 10510B-106-BG
Specification
| A Dimension In | 1.720 |
|---|---|
| A Dimension Mm | 43.690 |
| Angle Shape | Straight |
| Construction Style | Reusable |
| End Type 1 | Male pipe (NPTF) |
| Hose Cut Off Factor In | 0.970 |
| Hose Cut Off Factor Mm | 24.790 |
| Hose Size | -6 |
| Inside Diameter In | 0.430 |
| Inside Diameter Mm | 10.930 |
| Product Height In | 0.750 |
| Product Height Mm | 19.050 |
| Product Length In | 1.720 |
| Product Length Mm | 43.688 |
| Product Material | Brass |
| Product Width In | 0.750 |
| Product Width Mm | 19.050 mm |
| Series | 105 B |
| Thread Size 1 | 3/8-18 NPTF |
| Working Temperature Max C | 150 |
| Working Temperature Max F | 302 |
| Working Temperature Min C | -40 |
| Working Temperature Min F | -40 |
