Danfoss (Drives) 10411-36-16Z
HOSE NIPPLE ASSY,2P/16,DKOL/36,CS,STR – 10411-36-16Z
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
HOSE NIPPLE ASSY,2P/16,DKOL/36,CS,STR – 10411-36-16Z
Specification
| A Dimension In | 3.090 |
|---|---|
| A Dimension Mm | 78.500 |
| Angle Shape | Straight |
| Brand | Winner by Danfoss |
| Compatible Hose Id In | 1.000 |
| Compatible Hose Id Mm | 25.400 |
| Construction Style | Crimp |
| End Type 1 | 24 deg. DKO swivel light duty |
| Finish Plating | Zinc plating |
| Hex Size 1 In | 1.496 |
| Hex Size 1 Mm | 38.000 |
| Hex Size 2 In | 0.000 |
| Hose Cut Off Factor In | 1.240 |
| Hose Cut Off Factor Mm | 31.500 |
| Hose Size | -16 |
| Inside Diameter In | 0.8300 |
| Inside Diameter Mm | 21.0000 |
| Product Height In | 1.724 |
| Product Height Mm | 43.800 |
| Product Length In | 3.091 |
| Product Length Mm | 78.501 |
| Product Material | Carbon steel |
| Product Width In | 1.496 |
| Product Width Mm | 38.001 mm |
| Proposition 65 | Cancer and Reproductive Harm |
| Series | Winner 2-Piece |
| Thread Size 1 | M36x2 |
