Danfoss (Drives) 02-414322
FCG-H03-100-10, FCGH0310010 – 02-414322
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
FCG-H03-100-10, FCGH0310010 – 02-414322
Specification
| Brand | Vickers by Danfoss |
|---|---|
| Design Code | 10 Series |
| Flow Compensation | Pressure and Temperature |
| Flow Rate Gpm | 26.00 |
| Flow Rate Lpm | 100.00 |
| Fluid Cleanliness | 19/17/14 micron |
| Fluid Compatibility | Anti-wear hydraulic oil |
| Leakage | Standard |
| Model Code 1 | FCGH0310010 |
| Pressure Rating Bar | 315.00 |
| Pressure Rating Psi | 4600.00 |
| Product Height In | 5.790 |
| Product Height Mm | 147.066 |
| Product Length In | 4.860 |
| Product Length Mm | 123.444 |
| Product Width In | 4.860 |
| Product Width Mm | 123.444 |
| Seal Material | Nitrile |
| Size | 03 |
| Special Features | None |
| Valve Mount Type | Subplate |
| Valve Type | Flow control valve |
| Working Temp Max C | 80 |
| Working Temp Max F | 176 |
| Working Temp Min C | -30 |
| Working Temp Min F | -22 |
