Description
F3-CB-32-G-A-10-B60, F3CB32GA10B60 – 02-413615
Specification
| Brand | Vickers by Danfoss |
|---|---|
| Cracking Pressure Bar | 2.0 |
| Cracking Pressure Psi | 29 |
| Design Series | 10 Series |
| Flow Rate Lpm | 560.0 |
| Fluid Cleanliness | 20/18/15 Micron |
| Fluid Compatibility | Phosphate ester fluids |
| Model Code 1 | F3CB32GA10B60 |
| Product Height In | 4.720 |
| Product Height Mm | 119.888 |
| Product Length In | 12.160 |
| Product Length Mm | 308.864 |
| Product Width In | 4.720 |
| Product Width Mm | 119.888 |
| Seal Material | Fluorocarbon |
| Size | Size 32 |
| Valve Mount Type | Subplate mounted |
| Valve Type | Counterbalance valve |
| Working Temperature Max C | 80 |
| Working Temperature Max F | 176 |
| Working Temperature Min C | -20 |
| Working Temperature Min F | -4 |
