Danfoss (Drives) 02-413609
F3-CB-25-K-A-10-B40, F3CB25KA10B40 – 02-413609
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
F3-CB-25-K-A-10-B40, F3CB25KA10B40 – 02-413609
Specification
| Actuation Type | Manually operated |
|---|---|
| Brand | Vickers by Danfoss |
| Cracking Pressure Bar | 2.0 |
| Cracking Pressure Psi | 29 |
| Design Series | 10 Series |
| Drain | Internal |
| Electrical Connection | None |
| Flow Rate Lpm | 320.0 |
| Flow Rate Usgpm | 84.0 |
| Fluid Cleanliness | 20/18/15 Micron |
| Fluid Compatibility | Phosphate ester fluids |
| Leakage | Standard |
| Maximum Pressure Bar | 315 |
| Maximum Pressure Psi | 4500 |
| Model Code 1 | F3CB25KA10B40 |
| Performance | Standard |
| Product Height In | 9.960 |
| Product Height Mm | 252.984 |
| Product Length In | 3.150 |
| Product Length Mm | 80.010 |
| Product Width In | 3.150 |
| Product Width Mm | 80.01 |
| Remote Control | Yes |
| Seal Material | Fluorocarbon |
| Size | Size 25 |
| Special Feature | None |
| Stage | Single stage |
| Valve Mount Type | Cartridge valve |
| Valve Type | Counterbalance valve |
| Working Temperature Max C | 80 |
| Working Temperature Max F | 176 |
| Working Temperature Min C | -20 |
| Working Temperature Min F | -4 |
