Danfoss (Drives) 02-402304
DG17V-3-6A-60-EN706, DG17V36A60EN706 – 02-402304
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
DG17V-3-6A-60-EN706, DG17V36A60EN706 – 02-402304
Specification
| Actuation Type | Lever/knob operated |
|---|---|
| Brand | Vickers by Danfoss |
| Coil Rating | None |
| Design Series | 60 Series |
| Electrical Connection | None |
| Flow Rate Upto Gpm | 20.0 |
| Flow Rate Upto Lpm | 75.0 |
| Fluid Cleanliness | 19/17/14 micron |
| Fluid Compatibility | Petroleum oils |
| Indicator Light | No |
| Interface | ISO4401-03 |
| Manual Override | None |
| Model Code 1 | DG17V36A60EN706 |
| Performance | Standard performance |
| Pressure Rating Bar | 350 |
| Pressure Rating Psi | 5000.00 |
| Seal Type | WATER GLYCOL |
| Solenoid Energising Id | None |
| Special Features | Hydraulic pilot detent |
| Spool Position Monitor | No |
| Spool Type | Spool 6 |
| Spring Arrangement | Spring offset end to end |
| Stage | Single stage |
| Surge Suppr Damper | No |
| Tank Port Rating Bar | 7 |
| Tank Port Rating Psi | 100 |
| Valve Mount Type | Subplate/manifold mounted |
| Valve Type | Directional control valve |
| Working Temp Max C | 65 |
| Working Temp Max F | 150 |
| Working Temp Min C | -18 |
| Working Temp Min F |
