Description
F6-DG17V4-0131C-10, F6DG17V40131C10 – 02-393245
Specification
| Actuation Type | Manual lever operated |
|---|---|
| Brand | Vickers by Danfoss |
| Coil Rating | None |
| Design Series | 10 Series |
| Electrical Connection | None |
| Flow Rate Upto Gpm | 30.0 |
| Flow Rate Upto Lpm | 114.0 |
| Fluid Cleanliness | 20/18/15 micron |
| Fluid Compatibility | Petroleum oils |
| Indicator Light | No |
| Interface | ISO4401-05 |
| Manual Override | None |
| Model Code 1 | F6DG17V40131C10 |
| Performance | High performance |
| Pressure Rating Bar | 315 |
| Pressure Rating Psi | 4500 |
| Seal Type | WATER GLYCOL |
| Solenoid Energising Id | None |
| Special Features | None |
| Spool Position Monitor | No |
| Spool Type | Spool 31 |
| Spring Arrangement | Spring centred |
| Stage | Single stage |
| Surge Suppr Damper | No |
| Tank Port Rating Bar | 70.0 |
| Tank Port Rating Psi | 1000 |
| Valve Mount Type | Subplate/manifold mounted |
| Valve Type | Directional control valve |
| Working Temp Max C | 50 |
| Working Temp Max F | 122 |
| Working Temp Min C | 20 |
| Working Temp Min F | 70 |
