Danfoss (Drives) 02-352688
DGMFN 7 Y B2H 20, DGMFN7YB2H20 – 02-352688
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
DGMFN 7 Y B2H 20, DGMFN7YB2H20 – 02-352688
Specification
| Actuation Type | Pressure operated |
|---|---|
| Adjustment Type | Handknob |
| Brand | Vickers by Danfoss |
| Control Type 1 | Standard control |
| Design Series | 20 Series |
| Direction Of Flow | Meter-out control |
| Flow Rate Upto Lpm | 180 |
| Flow Rate Upto Usgpm | 48.0 |
| Fluid Cleanliness | 19/17/14 micron |
| Fluid Compatibility | Anti-wear hydraulic oil |
| Interface | ISO4401-07 |
| Location Control Function 1 | Line B |
| Maximum Pressure Upto Bar | 315 |
| Maximum Pressure Upto Psi | 4500 |
| Model Code | DGMFN7YB2H20 |
| Performance | Standard |
| Product Height In | 3.150 |
| Product Height Mm | 80.010 |
| Product Length In | 8.620 |
| Product Length Mm | 218.948 |
| Product Width In | 3.660 |
| Product Width Mm | 92.964 |
| Seal Type | Buna-N |
| Special Features | None |
| Valve Mount Type | Subplate/manifold mounted |
| Valve Type | Flow control valve |
| Working Temp Max C | 80 |
| Working Temp Max F | 176 |
| Working Temp Min C | -20 |
| Working Temp Min F | -4 |
