Danfoss (Drives) 02-348486
PVM018ER02AE01AAA0700000 0A0A, PVM018ER02AE01AAA0700000 0A0A – 02-348486
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
PVM018ER02AE01AAA0700000 0A0A, PVM018ER02AE01AAA0700000 0A0A – 02-348486
Specification
| P R O D U C T | VAR DISP OCP PVM PUMP |
|---|---|
| D I S P L A C E M E N T | 18.0 cm3/r [1.1 in3/r] (280 bar MAX) |
| Valve Plate | INDUSTRIAL (1800 r/min MAX) |
| Input Rotation | CLOCKWISE (RIGHTHAND) |
| Input Shaft | SAE J744-19-1 SAE 19-1 STRAIGHT KEYED (MODEL 018 AND 028) |
| Mounting Flange | SAE J744-82-2 (A 2-BOLT) (MODEL 018 AND 028) |
| Main Port Location | END (MODELS 018,020,045,050) |
| Port Options | SAE J514 TUBE PORTS SAE AUXILIARY PORTS |
| Pump Special Features | ADJUSTABLE MAX DISPLACEMENT STOP(CONTAINS SINGLE SHAFT SEAL) |
| C O N T R O L | PRESSURE COMPENSATOR |
| Pressure Comp Set | 66-74 BAR [957-1073 LBF/IN2] |
| Flow Comp Unld Vlv Rpc Set | NONE |
| Unld Vlv Tq Control Set | NONE |
| Comp Special Features | NONE |
| Auxiliary Mounting | NONE (REAR PORT ONLY) |
| Paint | BLACK [DEFAULT] |
| Customer Identification | NONE |
| Design Code | A |
| Brand | Vickers by Danfoss |
| Code Title | VICKERS VARIABLE DISPLACEMENT OPEN CIRCUIT PISTON PUMPS |
| Ipm Frame Size | PVM Code A 18cc Pump |
| Model Code 1 | PVM018ER02AE01AAA0700000 0A0A |
