Danfoss (Drives) 02-341563
PVQ20-B2R-SS3S-21-C21-12, PVQ20-B2R-SS3S-21-C21-12 – 02-341563
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
PVQ20-B2R-SS3S-21-C21-12, PVQ20-B2R-SS3S-21-C21-12 – 02-341563
Specification
| Series | INLINE PISTON PUMP WITH VARIABLE VOLUME, QUIET SERIES |
|---|---|
| D I S P L A C E M E N T | 21,1 CC/REV (1.29 cir), 210 BAR (3000 PSI) |
| Mounting Flange | SAE “B” 2 BOLT |
| Rotation (Viewed From S End) | RIGHT HAND (CW) |
| Thru Drive Without Coupling | NO THRU-DRIVE |
| Port Type And Location | SAE O-RING SIDE PORT, 1.625” INLET AND OUTLET (OPTIONAL) |
| Input Shaft | SPLINED SAE “B” MODIFIED, 13T 16/32 DP MAJOR DIA. FIT |
| S E A L S | BUNA N, STANDARD |
| Pump Design Number | 21-DESIGN NUMBER |
| C O N T R O L T Y P E | PRESSURE COMPENSATOR; INDICATING SETTING OF 210 BAR (3000 PSI); RANGE IS 02-21 IN TENS OF BAR (350-3000 PSI) |
| Control Option | WITHOUT ADJUSTABLE MAXIMUM DISPLACEMENT STOP (STANDARD) |
| Control Design | C14, C21, CM7, C**D AND CM**D |
| Special Pump Option Suffixes | NO SPECIAL PUMP SUFFIXES |
| Brand | Vickers by Danfoss |
| Ipm Frame Size | PVQ 20cc Pump |
| Model Code 1 | PVQ20-B2R-SS3S-21-C21-12 |
