Danfoss (Drives) 02-341539
PVQ20-B2R-A9-SS1S-21-C21V11B-13, PVQ20-B2R-A9-SS1S-21-C21V11B-13 – 02-341539
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
PVQ20-B2R-A9-SS1S-21-C21V11B-13, PVQ20-B2R-A9-SS1S-21-C21V11B-13 – 02-341539
Specification
| Series | INLINE PISTON PUMP WITH VARIABLE VOLUME, QUIET SERIES |
|---|---|
| D I S P L A C E M E N T | 21,1 CC/REV (1.29 cir), 210 BAR (3000 PSI) |
| Mounting Flange | SAE “B” 2 BOLT |
| Rotation (Viewed From S End) | RIGHT HAND (CW) |
| Thru Drive Without Coupling | SAE J744 82-2 (SAE A) W/9T SPLINE WITH SIDE PORTS ONLY) |
| Port Type And Location | SAE O-RING SIDE PORT, 1.625” INLET AND OUTLET (OPTIONAL) |
| Input Shaft | STRAIGHT KEYED SAE “B” MODIFIED, 2.31” LONG |
| S E A L S | BUNA N, STANDARD |
| Pump Design Number | 21-DESIGN NUMBER |
| C O N T R O L T Y P E | C21V11B-PRESSURE COMPENSATOR, WITH LOAD-SENSING. STANDARD LOAD-SENSING SETTING IS 11 BAR (160 PSI); RANGE 10-17 BAR (150-250PSI); WITH BLEED DOWN ORIFICE |
| Control Option | WITHOUT ADJUSTABLE MAXIMUM DISPLACEMENT STOP (STANDARD) |
| Control Design | C**V(C)**B AND C**V(C)**P |
| Special Pump Option Suffixes | NO SPECIAL PUMP SUFFIXES |
| Brand | Vickers by Danfoss |
| Ipm Frame Size | PVQ 20cc Pump |
| Model Code 1 | PVQ20-B2R-A9-SS1S-21-C21V11B- |
| Model Code 2 | 13 |
