Danfoss (Drives) 02-323675
CVGCPAV 3 W 250 10, CVGCPAV3W25010 – 02-323675
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
CVGCPAV 3 W 250 10, CVGCPAV3W25010 – 02-323675
Specification
| Adjustment | Yes |
|---|---|
| Adjustment Type | Wrench with hex locknut |
| Brand | Vickers by Danfoss |
| Design Series | 10 Design |
| Flow Rate Lpm | 5 |
| Flow Rate Usgpm | 1.3 |
| Fluid Cleanliness | 18/16/13 micron |
| Fluid Compatibility | Water Glycol, Water-in-Oil Emulsions and Petroleum Oil |
| Gauge Port Thread | SAE |
| Insert Type | Relief |
| Interface | Yes |
| Leakage | Standard |
| Model Code 1 | CVGCPAV3W25010 |
| Module Type | Relief P & A-T |
| Normal Function | Normally closed |
| Pilot Port Orientation | ISO |
| Pressure Rating Bar | 350 |
| Pressure Rating Psi | 5000.00 |
| Seal Material | Buna-N |
| Size | ISO 4401, size 03 |
| Special Feature | None |
| Spool Position Sensor | No |
| Valve Type | Cartridge valve module |
| Valvistor | No |
| Working Temp Max C | 70 |
| Working Temp Max F | 158 |
| Working Temp Min C | -20 |
| Working Temp Min F | -4 |
