Description
CVCS-50-ZD3-B2-10, CVCS50ZD3B210 – 02-319438
Specification
| Adjustment | No |
|---|---|
| Brand | Vickers by Danfoss |
| Cover Type | Dynamic with pilot control |
| Design Series | 10 Design |
| Flow Rate Lpm | 2350 |
| Flow Rate Usgpm | 620.0 |
| Fluid Cleanliness | 18/16/13 micron |
| Fluid Compatibility | Water Glycol, Water-in-Oil Emulsions and Petroleum Oil |
| Gauge Port Thread | BSPF |
| Insert Ratio | 1:1.05 |
| Insert Type | Dynamic, Zero Pilot Leakage |
| Interface | Yes |
| Leakage | Zero leakage |
| Model Code 1 | CVCS50ZD3B210 |
| Normal Function | Normally open |
| Pilot Port Orientation | ISO |
| Pressure Rating Bar | 350 |
| Pressure Rating Psi | 5000 |
| Product Height In | 5.690 |
| Product Height Mm | 144.526 |
| Product Length In | 7.500 |
| Product Length Mm | 190.500 |
| Product Width In | 5.810 |
| Product Width Mm | 147.574 |
| Seal Material | Buna-N |
| Size | NG 50 |
| Special Feature | None |
| Spool Position Sensor | No |
| Valve Type | Cartridge valve cover |
| Valvistor | No |
| Working Temp Max C | 70 |
| Working Temp Max F | 158 |
| Working Temp Min C | -20 |
| Working Temp Min F | -4 |
