Danfoss (Drives) 02-318820-D
V10 1B5B 41D 20 090, V10 1B5B 41D 20 090 – 02-318820-D
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
V10 1B5B 41D 20 090, V10 1B5B 41D 20 090 – 02-318820-D
Specification
| Pump Type | VANE PUMP |
|---|---|
| Series | SERIES DESIGNATION |
| Mounting Type | 2 BOLT FLANGE SAE-A SIZE |
| Inlet Port Type | BSP THREAD PER DS1106 |
| Ring Capacity | 5 GPM |
| Outlet Port Type | BSP THREAD PER DS1104 |
| Shaft Type | 9 TEETH 16/32, MAJOR DIA-0.608, EXTENSION-1.25 |
| Outlet Cover Port Orientation | 90° CW FROM INLET PORT |
| Design Code | DESIGN CODE FOR NF,S,F COVER |
| Shaft Rotation | RH CW ROTATION VIEWED FROM SHAFT END |
| Special Feature Suffix | STD V10 PUMP WITH EXTRA TEST POINT AT 600 RPM AND 2300 PSI ON TP 6519 |
| Brand | Vickers by Danfoss |
| Ipm Frame Size | V10 Single Pump |
| Model Code 1 | V10 1B5B 41D 20 090 |
