Danfoss (Drives) 02-318400
CVCS-63-ZD3-B2-10, CVCS63ZD3B210 – 02-318400
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
CVCS-63-ZD3-B2-10, CVCS63ZD3B210 – 02-318400
Specification
| Adjustment | No |
|---|---|
| Brand | Vickers by Danfoss |
| Cover Type | Dynamic with pilot control |
| Design Series | 10 Design |
| Flow Rate Lpm | 3650 |
| Flow Rate Usgpm | 965.0 |
| Fluid Cleanliness | 18/16/13 micron |
| Fluid Compatibility | Water Glycol, Water-in-Oil Emulsions and Petroleum Oil |
| Gauge Port Thread | BSPF |
| Insert Ratio | 1:1.05 |
| Insert Type | Dynamic, Zero Pilot Leakage |
| Interface | Yes |
| Leakage | Zero leakage |
| Model Code 1 | CVCS63ZD3B210 |
| Normal Function | Normally open |
| Pilot Port Orientation | ISO |
| Pressure Rating Bar | 350 |
| Pressure Rating Psi | 5000 |
| Product Height In | 10.130 |
| Product Height Mm | 257.302 |
| Product Length In | 7.200 |
| Product Length Mm | 182.880 |
| Product Width In | 7.200 |
| Product Width Mm | 182.88 |
| Seal Material | Buna-N |
| Size | NG 63 |
| Special Feature | None |
| Spool Position Sensor | No |
| Valve Type | Cartridge valve cover |
| Valvistor | No |
| Working Temp Max C | 70 |
| Working Temp Max F | 158 |
| Working Temp Min C | -20 |
| Working Temp Min F | -4 |
