Danfoss (Drives) 02-159983-CAR
25VQTAS 21A 2297CA 20R, 25VQTAS 21A 2297CA 20R – 02-159983-CAR
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
25VQTAS 21A 2297CA 20R, 25VQTAS 21A 2297CA 20R – 02-159983-CAR
Specification
| Pump Type | INTRAVANE PUMP |
|---|---|
| Series | INTRAVANE PUMP SERIES WITH STANDARD BEARING |
| Shaft Type | 297 – SAE B SPLINED, 13 TEETH (DOUBLE SHAFT SEAL) |
| Rot From Shaft End | RIGHT HAND OR CLOCKWISE |
| Thru Drive | THRU DRIVE |
| Adpmtg Ort Adp End | A ADAPTER- ROTATED 45⁰ CW WITH RESPECT TO PUMP MTG. FLG. B OR C ADAPTER- IN LINE WITH PUMP MTG. FLANGE |
| Body Mounting Flg | SAE J744 MOUNTING FLANGE |
| Brand | Vickers by Danfoss |
| Cplg For Tand Pump | SAE SPLINED COUPLING INCLUDED WITH PUMP |
| Design No Mod | DESIGN CODE-SINGLE SS |
| Ipm Frame Size | 25VQ Single Pump |
| Model Code 1 | 25VQTAS 21A 2297CA 20R |
| Outlet Pos From Adp End | IN LINE WITH INLET PORT |
| Rotating Group Cap | 21 GPM |
| Sae Port Cxn | INLET-4 BOLT FLG. OUTLET-4 BOLT FLG. |
| Thru Cxn Mtg Adp | TWO BOLT SAE ‘A’ FLANGE |
