Danfoss (Drives) 02-137133-1
35V38A 11A22R, 35V38A 11A22R – 02-137133-1
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
35V38A 11A22R, 35V38A 11A22R – 02-137133-1
Specification
| Ipm Frame Size | 35V Single Pump |
|---|---|
| Outlet Post Frm Cvr End | OUTLET OPPOSITE INLET |
| Port Connection | INLET: 4 BOLT FLANGE OUTLET: 4 BOLT FLANGE |
| Pump Type | VANE PUMP |
| Ring Capacity | 38 GPM |
| Series | SERIES DESIGNATION |
| S H A F T | 11- 14T 12/24 MDF SPLINE |
| Port Thread Type | INCH THREAD PORT CONNECTION |
| Rotation From Shaftend | CLOCKWISE |
| M O U N T I N G | FLANGE MOUNT |
| Model Code 1 | 35V38A 11A22R |
