Danfoss (Drives) 02-125512-AAL
35VTBS30A 2203AA 22L, 35VTBS30A 2203AA 22L – 02-125512-AAL
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
35VTBS30A 2203AA 22L, 35VTBS30A 2203AA 22L – 02-125512-AAL
Specification
| Design No | DESIGN NO |
|---|---|
| Ipm Frame Size | 35VT Thru-Drive Pump |
| Port Connection | INLET: 4 BOLT FLANGE OUTLET: 4 BOLT FLANGE |
| Pump Type | VANE PUMP, THRU DRIVE |
| Ring Capacity | 30 GPM |
| Rotation From Shaft End | COUNTER CLOCKWISE |
| Series | SERIES DESIGNATION |
| S H A F T | 203- STRAIGHT KEY, HEAVY DUTY |
| Body Mounting Flange | SAE J-744 101-2 MOUNTING FLANGE |
| Adapter Mtg Orientation | FOR ADAPTER ‘A’ : ROTATE 45° CW WITH RESPECT TO MOUNTING FLANGE VIEWED FROM ADAPTER END. FOR ADAPTER ‘B’, ‘C’: INLINE WITHMOUNTING FLANGE. |
| C O U P L I N G | WITH SPLINE FOR TANDEM PUMP |
| Outlet Position | OUTLET OPPOSITE INLET |
| Thru Connection Mtg | TWO BOLT SAE ‘B’ FLANGE |
| Brand | Vickers by Danfoss |
| Model Code 1 | 35VTBS30A 2203AA 22L |
