Danfoss (Drives) 02-125379-1
25VTAS14A 2202AA 22R, 25VTAS14A 2202AA 22R – 02-125379-1
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
25VTAS14A 2202AA 22R, 25VTAS14A 2202AA 22R – 02-125379-1
Specification
| Design No | DESIGN NO – 22 |
|---|---|
| Ipm Frame Size | 25VT Thru-Drive Pump |
| Port Connection | INLET: 4 BOLT FLANGE OUTLET: 4 BOLT FLANGE |
| Pump Type | VANE PUMP, THRU DRIVE |
| Ring Capacity | 14 GPM |
| Rotation From Shaft End | CLOCKWISE |
| Series | SERIES DESIGNATION |
| S H A F T | 202- SAE ‘B’ SQUARE KEY |
| Body Mounting Flange | SAE J-744 101-2 MOUNTING FLANGE |
| Adapter Mtg Orientation | FOR ADAPTER ‘A’ : ROTATE 45° CW WITH RESPECT TO MOUNTING FLANGE VIEWED FROM ADAPTER END. FOR ADAPTER ‘B’: INLINE WITH MOUNTINGFLANGE |
| C O U P L I N G | WITH SPLINE FOR TANDEM PUMP |
| Outlet Position | OUTLET OPPOSITE INLET |
| Thru Connection Mounting | TWO BOLT SAE ‘A’ FLANGE |
| Brand | Vickers by Danfoss |
| Model Code 1 | 25VTAS14A 2202AA 22R |
