Description
CG5V 6GM D M U H7 11, CG5V6GMDMUH711 – 02-108790
Specification
| Actuation Type | Solenoid operated |
|---|---|
| Adjustment Range | 3-350 bar (44-5000 psi) |
| Adjustment Type | Micrometer without keylock |
| Brand | Vickers by Danfoss |
| Coil Voltage | 24 VDC |
| Design Series | 11 Series |
| Electrical Connection | ISO4400 (Din 43650) Connector |
| Flow Rate Lpm | 400.0 |
| Flow Rate Usgpm | 106.0 |
| Indicator Light | No |
| Interface | ISO6264 AR-06-2-A |
| Maximum Pressure Bar | 350 |
| Maximum Pressure Psi | 5000 |
| Model Code 1 | CG5V6GMDMUH711 |
| Product Height In | 8.000 |
| Product Height Mm | 203.200 |
| Product Length In | 6.700 |
| Product Length Mm | 170.180 |
| Product Width In | 3.230 |
| Product Width Mm | 82.042 mm |
| Stage | Two stage |
| Valve Mount Type | Subplate mounted |
| Valve Type | Relief valve |
