Danfoss (Drives) 02-108784
F3 CVU 25 EFP1 B29 45 31, F3CVU25EFP1B294531 – 02-108784
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
F3 CVU 25 EFP1 B29 45 31, F3CVU25EFP1B294531 – 02-108784
Specification
| Adjustment | No |
|---|---|
| Brand | Vickers by Danfoss |
| Cover Type | Electrohyd proportional throttle valve |
| Cracking Pressure Bar | 2.50 |
| Cracking Pressure Psi | 36.0 |
| Design Series | 31 Design |
| Flow Rate Lpm | 450 |
| Flow Rate Usgpm | 119.0 |
| Fluid Cleanliness | 18/16/13 micron |
| Fluid Compatibility | Phosphate Ester and other Synthetic Fire Resistant Fluids |
| Gauge Port Thread | BSPF |
| Insert Ratio | 1:1.4 |
| Interface | No |
| Leakage | Standard |
| Model Code 1 | F3CVU25EFP1B294531 |
| Pilot Port Orientation | ISO |
| Pressure Rating Bar | 315 |
| Pressure Rating Psi | 4500 |
| Product Height In | 7.850 |
| Product Height Mm | 199.390 |
| Product Length In | 5.850 |
| Product Length Mm | 148.590 |
| Product Width In | 3.350 |
| Product Width Mm | 85.090 mm |
| Seal Material | Viton |
| Size | NG 25 |
| Special Feature | None |
| Spool Position Sensor | No |
| Valve Type | Cartridge valve unit |
| Valvistor | No |
| Working Temp Max C | 70 |
| Working Temp Max F | 158 |
| Working Temp Min C | -20 |
| Working Temp Min F | -4 |
