B&R 5PC820.SX01-00
Specially developed to operate together with ACOPOSmultiCold plate or feed-through mounting1 PCI Express compact slotSRAM, 1 MB onboardIntegrated POWERLINK and CAN fieldbus interfaces…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Specially developed to operate together with ACOPOSmultiCold plate or feed-through mounting1 PCI Express compact slotSRAM, 1 MB onboardIntegrated POWERLINK and CAN fieldbus interfaces
APC820 system unit, cold plate mounting, 1 PCIec card slot, 2x CompactFlash slots, 1x RS232, 1x RS232/422/485, 1x POWERLINK, 1x CAN, Smart Display Link/DVI/monitor, 5x USB 2.0, 2x ETH 10/100/1000, 24 VDC via ACOPOSmulti rail.
Specification
| Dongle port | Yes |
|---|---|
| LEDs | Power, CF, Link, Run, CAN, POWERLINK, IF slot |
| B&R ID code | 0xA7DE |
| Type | SDL/DVI/Monitor |
| Service life | 2 years |
| Removable | Yes, behind the cable cover |
| Variant | DVI-I |
| Power button | Yes |
| Reset button | Yes |
| Buzzer | Yes |
| Cooling and mounting type | Cold plate or pass-through mounting |
| CE | Yes |
| UKCA | Yes |
| UL | cULus E115267 Industrial control equipment |
| Bootloader | BIOS |
| Cooling | Passive via heat sink and supported with an active fan kit |
| Accuracy | At 25°C: Typ. 12 ppm (1 second) per day |
| Battery-backed | Yes |
| Controller | Intel Graphics Media Accelerator 950 |
| Buffer time | 10 ms |
| Size | 1 MB |
| Remanent variables in power failure mode | 128 kB (for e.g. Automation Runtime, see Automation Help) |
| UART | 16550-compatible, 16-byte FIFO buffer |
| Max. baud rate | 1000 Mbit/s |
| Quantity | 1 |
| Connection | To any USB type A interface |
| Transfer rate | Max. 500 kbit/s |
| Current-carrying capacity | Max. 500 mA or 1 A per interface |
| Node switches | Yes |
| Status LED | Yes |
| Terminating resistor | Yes, can be enabled via switch |
| Nominal voltage | 24 VDC ±25% |
| Nominal current | 5 A |
| Inrush current | Typ. 7 A, max. 50 A for < 300 µs |
| Drop height | 0.25 m |
| Degree of protection per EN 60529 | IP20 |
| Operation | Max. 3000 m (component-dependent) |
| Storage | 2 to 9 Hz: 3.5 mm amplitude / 9 to 200 Hz: 1 g / 200 to 500 Hz: 1.5 g |
| Transport | 2 to 9 Hz: 3.5 mm amplitude / 9 to 200 Hz: 1 g / 200 to 500 Hz: 1.5 g |
| Material | Galvanized plate, plastic |
| Front cover | Polycarbonates, black |
| Cable cover | Polycarbonates, transparent |
| Width | 53 mm |
| Height | 344 mm |
| Depth | 205 mm |
| Weight | Approx. 1850 g |
