B&R 5PC820.1906-00
19″ TFT SXGA color displayAnalog resistive touch screenRobust designCompact installation depthFanless operation1 optional PCI Express compact slot1 optional slide-in compact slotOptional PCI and PCIe…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
19″ TFT SXGA color displayAnalog resistive touch screenRobust designCompact installation depthFanless operation1 optional PCI Express compact slot1 optional slide-in compact slotOptional PCI and PCIe slots and optional slide-in drives, optional expansions available
Panel PC 820 19″ SXGA color TFT display with touch screen (resistive), connections for 1x RS232, 5x USB 2.0, Smart Display Link/DVI/monitor, 2x Ethernet 10/100/1000, HDA sound, add-on UPS slot, can be expanded with 1 or 2 PCI / PCI Express slots, optional PCI Express compact and slide-in compact slot, IP65 protection (front), order 24 VDC connector for power supply separately (screw clamp terminal block: 0TB103.9, cage clamp terminal block: 0TB103.91).
Specification
| LEDs | Power, HDD, Link, Run |
|---|---|
| B&R ID code | 0xAF22 |
| Type | HDA sound |
| Service life | 2½ years |
| Removable | Yes, accessible from the outside |
| Variant | Shielded RJ45 port |
| Power button | Yes |
| Reset button | Yes |
| Buzzer | Yes |
| CE | Yes |
| UKCA | Yes |
| UL | cULus E115267Industrial control equipment |
| Bootloader | BIOS |
| Controller | Elo, serial, 12-bit |
| Buffer time | 10 ms |
| Diagonal | 19″ (480 mm) |
| Colors | 16 million |
| Resolution | SXGA, 1280 x 1024 pixels |
| Contrast | 1000:1 |
| Horizontal | Direction R = 89° / Direction L = 89° |
| Vertical | Direction U = 89° / Direction D = 89° |
| Brightness | 300 cd/m² |
| Half-brightness time | 50,000 h |
| Technology | Analog, resistive |
| Transmittance | 81% ±3% |
| UART | 16550-compatible, 16-byte FIFO buffer |
| Max. baud rate | 115 kbit/s |
| Quantity | Optional |
| Transfer rate | 10/100/1000 Mbit/s |
| Current-carrying capacity | Max. 500 mA or 1 A per connection |
| Inputs | Microphone, Line In |
| Outputs | Line Out |
| Slide-in drives | Component-dependent (on the expansion and bus unit used) |
| Slide-in compact drives | Optional |
| Add-on UPS slot | Yes |
| Slot for fan kit | Yes |
| Nominal voltage | 24 VDC ±25%, SELV |
| Nominal current | 6 A |
| Inrush current | Typ. 10 A, max. 50 A for < 300 μs |
| Power consumption | Component-dependent |
| Overvoltage category per EN 61131-2 | II |
| Galvanic isolation | Yes |
| Drop height | 1 m on industrial floor (in original packaging) |
| Degree of protection per EN 60529 | Back: IP20Front: IP65, protected against dust and hose-directed water |
| Operation | 15 g, 11 ms |
| Storage | 30 g, 15 ms |
| Transport | 30 g, 15 ms |
| Operation (continuous) | 2 to 9 Hz: 1.75 mm amplitude / 9 to 150 Hz: 0.5 g |
| Operation (occasional) | 2 to 9 Hz: 3.5 mm amplitude / 9 to 150 Hz: 1 g |
| Material | Polyester |
| Frame | Aluminum, naturally anodized |
| Design | Gray |
| Light background color | Similar to Pantone 427CV |
| Gasket | Flat gasket around display front |
| Width | 527 mm |
| Height | 421 mm |
| Depth | Component-dependent |
| Weight | 10000 g (component-dependent) |
