B&R 5PC810.SX03-00
Slot for a bus unit with 2 PCI and 1 PCIe slots512 kB SRAM onboardInsert for 1 slide-in compact drive and 1 slide-in driveAutomation Panel Link slot for connecting Automation Panels via SDL…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Slot for a bus unit with 2 PCI and 1 PCIe slots512 kB SRAM onboardInsert for 1 slide-in compact drive and 1 slide-in driveAutomation Panel Link slot for connecting Automation Panels via SDL
APC810 system unit 3 slots (PCI Ex- press, PCI, depends on bus), 1 slot for Automation Panel Link transmitter, 1 slide-in compact and 1 slide-in slot, Smart Display Link/DVI/Monitor, 2x RS232, 5x USB 2.0, 2x ETH 10/100/1000, AC97 sound, 24 VDC (order screw clamp terminal block 0TB103.9 or cage clamp terminal block 0TB103.91 separately)
Specification
| Dongle port | Yes |
|---|---|
| LEDs | Power, HDD, Link 1, Link 2 |
| B&R ID code | 0xB2C3 |
| Cooling | Passive via heat sink and optionally supported with an active fan kit |
| Type | AC97 sound |
| Service life | 2½ years |
| Removable | Yes, accessible behind the orange front door |
| Variant | Female DVI-I connector |
| Power button | Yes |
| Reset button | Yes |
| Buzzer | Yes |
| CE | Yes |
| UKCA | Yes |
| UL | cULus E115267 Industrial control equipment |
| Bootloader | BIOS |
| Battery-backed | Yes |
| Controller | Depends on the CPU board being used |
| Buffer time | 10 ms |
| Size | 512 kB |
| Remanent variables in power failure mode | 192 kB (for e.g. Automation Runtime, see Automation Help) |
| UART | 16550-compatible, 16-byte FIFO buffer |
| Max. baud rate | 1 Gbit/s |
| Quantity | 2 PCI and 1PCIe slot |
| Transfer rate | 10/100/1000 Mbit/s |
| Current-carrying capacity | Max. 500 mA or 1 A per connection |
| Note | optional |
| Inputs | Microphone, Line In |
| Outputs | Line Out |
| Slide-in drives | 1 |
| Slide-in compact drives | 1 |
| Automation Panel Link slot | Yes |
| Add-on UPS slot | Yes |
| Slot for fan kit | Yes |
| Nominal voltage | 24 VDC ±25%, SELV |
| Nominal current | 6 A |
| Inrush current | Typ. 7 A, max. 50 A for < 300 µs |
| Overvoltage category per EN 61131-2 | II |
| Galvanic isolation | Yes |
| Degree of protection per EN 60529 | IP20 |
| Operation | Max. 3000 m (component-dependent) |
| Storage | 30 g, 15 ms |
| Transport | 30 g, 15 ms |
| Operation (continuous) | 2 to 9 Hz: 1.75 mm amplitude / 9 to 200 Hz: 0.5 g |
| Operation (occasional) | 2 to 9 Hz: 3.5 mm amplitude / 9 to 200 Hz: 1 g |
| Material | Galvanized plate, plastic |
| Front cover | Dyed orange plastic (similar to Pantone 144CV) |
| Coating | Light gray (similar to Pantone 427CV), dark gray (similar to Pantone 432CV) |
| Width | 140.8 mm with heat sink 5AC801.HS00-00 and 5AC801.HS00-02 156.5 mm with heat sink 5AC801.HS00-01 |
| Height | 270 mm |
| Depth | 254.6 mm |
| Weight | Approx. 3200 g (component-dependent) |
