B&R 5PC800.B945-05
Intel® Atom™ N270 1.66 GHzIntel® 945GME chipset2x DDR2 memory socketIntel® GMA 950AMI BIOS
Intel Atom N270 CPU board, 1.6 GHz, single cor…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Intel® Atom™ N270 1.66 GHzIntel® 945GME chipset2x DDR2 memory socketIntel® GMA 950AMI BIOS
Intel Atom N270 CPU board, 1.6 GHz, single core, 533 MHz FSB, 512 kB L2 cache, 945GME chipset, 2 sockets for SO-DIMM DDR2 modules (max. expansion 3 GB), Realtek Ethernet Controller RTL8111C.
Specification
| CE | Yes |
|---|---|
| UKCA | Yes |
| UL | cULus E115267 Industrial control equipment |
| Bootloader | Embedded AMI BIOS |
| Type | DDR2 |
| Clock frequency | 1660 MHz |
| Number of cores | 1 |
| Architecture | 45 nm |
| L1 cache | 24 kB |
| L2 cache | 512 kB |
| External bus | 533 MHz |
| Intel 64 architecture | No |
| Intel Virtualization Technology (VT-x) | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Chipset | Intel 945GME Intel 82801 GHM (ICH7M-DH) |
| Accuracy | At 25°C: Typ. 12 ppm (1 second) per day |
| Battery-backed | Yes |
| Memory size | Max. 3 GB |
| Controller | Intel® Graphics Media Accelerator 950 |
| Memory | Up to 224 MB |
| Color depth | Max. 32-bit |
| DVI | 2x Intel-compliant SDVO ports, 1920 x 1080 |
| RGB | 400 MHz RAMDAC, resolution up to 2048 x 1536 @75 Hz (QXGA) and 1920 x 1080 @85 Hz (HDTV) |
| Mass memory management | 2x SATA, 1x IDE |
| Power management | ACPI 2.0, S3 support (suspend to RAM) |
