B&R 5PC781.1505-00
Panel PC 781 15″ XGA, 0 PCI slots, 15″ XGA color TFT display with touch screen (resistive), 12 soft keys, 20 function and 92 system keys, connections for 2x RS232, 3x USB 2.0, monitor, 2x Ethernet 10/…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Panel PC 781 15″ XGA, 0 PCI slots, 15″ XGA color TFT display with touch screen (resistive), 12 soft keys, 20 function and 92 system keys, connections for 2x RS232, 3x USB 2.0, monitor, 2x Ethernet 10/100, AC97 sound, PS/2 keyboard/mouse, IP65 protection (front), 24 VDC. Order connector for power supply separately (screw clamp terminal block: 0TB103.9, cage clamp terminal block: 0TB103.91).
Specification
| Dongle port | Yes |
|---|---|
| LEDs | Power, HDD, Link 1 |
| B&R ID code | 0x1C5F |
| Cooling | Fan slot for fan kit |
| Type | – |
| Service life | >1,000,000 actuations at 1 ±0.3 N to 3 ±0.3 N actuating force |
| Removable | Yes, accessible from the outside |
| Variant | – |
| Power button | Yes |
| Reset button | Yes |
| Buzzer | Yes |
| Keyboard/Mouse | PS/2 (combined) |
| CE | Yes |
| UKCA | Yes |
| UL | cULus E115267 Industrial control equipment |
| Note | optional |
| Diagonal | 15″ (381 mm) |
| Colors | 10 million |
| Resolution | XGA, 1024 x 768 pixels |
| Contrast | 1000:1 |
| Horizontal | Direction R / Direction L = 85° |
| Vertical | Direction U / Direction D = 85° |
| Brightness | 350 cd/m² |
| Half-brightness time | 70,000 h |
| Technology | Analog, resistive |
| Controller | Elo, serial, 12-bit |
| Transmittance | Up to 81% ±3% |
| UART | 16550-compatible, 16-byte FIFO buffer |
| Max. baud rate | 100 Mbit/s |
| Quantity | – |
| Transfer rate | 10/100 Mbit/s |
| Inputs | Microphone, Line In |
| Outputs | Line Out |
| Function keys | 20 with LED (yellow) |
| Soft keys | 12 with LED (yellow) |
| System keys | Alphanumeric keys, numeric keys, cursor block |
| Yellow | Typ. 12 mcd |
| Standard | – |
| Bus speed | – |
| Slide-in drives | No |
| Add-on drives | optional |
| Automation Panel Link slot | No |
| Slot for fan kit | Yes |
| Nominal voltage | 24 VDC ±25% |
| Nominal current | 3.8 A |
| Inrush current | Typ. 10 A, max. 40 A for < 300 μs |
| Galvanic isolation | Yes |
| Degree of protection per EN 60529 | Front: IP65 / NEMA 250 type 4X indoor, protected against dust and hose-directed water Back: IP20 (only with connected CF card) |
| Operation | Max. 3000 m |
| Storage | 30 g, 15 ms |
| Transport | 30 g, 15 ms |
| Operation (continuous) | 2 to 9 Hz: 1.75 mm amplitude / 9 to 200 Hz: 0.5 g |
| Operation (occasional) | 2 to 9 Hz: 3.5 mm amplitude / 9 to 200 Hz: 1 g |
| Material | Polyester |
| Frame | Aluminum, naturally anodized |
| Design | Gray |
| Light background color | Similar to Pantone 427CV |
| Dark border color around display | Similar to Pantone 432CV |
| Dark gray keys color | Similar to Pantone 431CV |
| Orange keys color | Similar to Pantone 151CV |
| Color slide-in labels | Similar to Pantone 429CV |
| Gasket | Flat gasket around display front |
| Width | 435 mm |
| Height | 430 mm |
| Depth | 86.3 mm with heat sink 5AC700.HS01-01 or 5AC700.HS01-03 101.5 mm with heat sink 5AC700.HS01-02 |
| Weight | Approx. 7500 g (component-dependent) |
