B&R 5PC725.1505-00
15″ TFT XGA color displayAnalog resistive touch screenIP65 protectionFan-free operationFlange output on top for mounting on a support arm system…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
15″ TFT XGA color displayAnalog resistive touch screenIP65 protectionFan-free operationFlange output on top for mounting on a support arm system
Panel PC 725 15″ XGA, 15″ XGA color TFT display with touch screen (resistive), connections for 1x RS232, 3x USB 2.0, 2x Ethernet 10/100, IP65 protection, 24 VDC. Flange installation on top. Order connector for power supply separately (screw clamp terminal block: 0TB103.9, cage clamp terminal block: 0TB103.91).
Specification
| LEDs | No |
|---|---|
| B&R ID code | 0xB046 |
| Type | USB 2.0 |
| Service life | 4 years |
| Removable | Yes, accessible from the outside |
| Variant | Type A |
| Power button | No |
| Reset button | No |
| Buzzer | Yes |
| CE | Yes |
| UKCA | Yes |
| UL | cULus E115267 Industrial control equipment |
| Bootloader | AMI BIOS |
| Controller | B&R, serial, 12-bit |
| Buffer time | 10 ms |
| Size | – |
| Battery-backed | – |
| Diagonal | 15″ (381 mm) |
| Colors | 16 million |
| Resolution | XGA, 1024 x 768 pixels |
| Contrast | 800:1 |
| Horizontal | Direction R / Direction L = 80° |
| Vertical | Direction U / Direction D = 80° |
| Brightness | 350 cd/m² |
| Half-brightness time | 50,000 h |
| Technology | Analog, resistive |
| Transmittance | 81% ±3% |
| UART | 16550-compatible, 16-byte FIFO buffer |
| Max. baud rate | 100 Mbit/s |
| Quantity | 1 |
| Transfer rate | 10/100 Mbit/s |
| Nominal voltage | 24 VDC ±25% |
| Nominal current | 1.4 A |
| Inrush current | Typ. 10 A, max. 40 A for < 300 μs |
| Power consumption | 28.5 W |
| Galvanic isolation | Yes |
| Degree of protection per EN 60529 | IP65 (all sides, only with closed housing) |
| Operation | 15 g, 11 ms |
| Storage | 30 g, 6 ms |
| Transport | 30 g, 6 ms |
| Material | Polyester |
| Frame | Aluminum, naturally anodized |
| Design | Gray |
| Gasket | Metamoll |
| Flange output | Top |
| Width | 426 mm |
| Height | 330 mm (without flange) 402 mm (with flange) |
| Depth | 58.7 mm (without flange) 83.2 mm (with flange) |
| Weight | 6.27 kg (without flange) |
