Banner Engineering QS30ARH2O W/30
WORLD-BEAM QS30 Series: H2O Receiver
Range: 2 m; Input: 10-30 V dc
Output: LO; Bipolar: 1 NPN; 1 PNP
9 m (30 ft) Cable
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
WORLD-BEAM QS30 Series: H2O Receiver
Range: 2 m; Input: 10-30 V dc
Output: LO; Bipolar: 1 NPN; 1 PNP
9 m (30 ft) Cable
Specification
| Power | DC |
|---|---|
| Sensing Beam | Long Infrared (Water Detection) |
| Cable Length (M) | 9 |
| Ip Rating | IP67 |
| Nema / Ul Type Rating | NEMA PW12 |
| Supply Voltage | 10-30 V dc |
| Item Status | INACTIVE |
| Sensing Mode (General) | Opposed |
| Sensing Mode (Detailed) | Receiver |
| Housing Style | Rectangular w/M30 Mount |
| Primary Housing Material | Thermoplastic |
| Input/ Output | Discrete |
| Max Sensing Distance (Mm) | 2000 |
| Outputs | Bipolar (NPN & PNP) |
| Connection | Cable |
| Operation | Light Operate |
| Min Op. Temperature (C) | -20 |
| Max Op. Temp. (C) | 60 |
| Output Response Time (Ms) | 1 |
| Special Feature: Intrinsically Safe | No |
| Special Feature: Remote Teach | No |
| Special Feature: Water Detection | Yes |
| Delay At Power Up (Ms) | 100 |
| Repeatability (µS) | 500 |
| Number Of Pins | 5 |
| Max Op. Relative Humidity [%] | 95% @ 50°C |
| Lens Material | Acrylic |
| Adjustments | N/A |
| Barrel Diameter (Mm) | 30 |
| Indicator | LEDs |
| Opposed Mode Emitter/Receiver | Receiver |
| Feature: Washdown Rated | No |
| Feature: Clear Object Detection | No |
| Feature: Timing (Hold/Delay) | No |
| Feature: Audible | No |
| Feature: Chemical Resistant | No |
| Feature: Quick Disconnect | No |
| Feature: Health/Marginal Signal Output | No |
| Device Net | No |
