Banner Engineering DXM150-B1
DXM150 Controller
I/O Base Board Only
Inputs: 2 Discrete, 8 Universal
Outputs: 2 Relay, 4 Discrete, 2 Analog
SAM4 Processor, LCD Display
RS-485, Ethernet, USB,…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
DXM150 Controller
I/O Base Board Only
Inputs: 2 Discrete, 8 Universal
Outputs: 2 Relay, 4 Discrete, 2 Analog
SAM4 Processor, LCD Display
RS-485, Ethernet, USB, CAN, RS-232; Solar/Battery Controller
Specification
| Power | DC |
|---|---|
| Ip Rating | IP20 |
| Ethernet Connector Type | RJ45 Jack |
| Nema / Ul Type Rating | NEMA 4X |
| Supply Voltage | 12-30 V dc |
| Item Status | RELEASED |
| Housing Style | External Terminals |
| Device Type | Wireless Controller |
| Input/ Output | Analog & Discrete |
| Occupancy | No |
| Analog Inputs | Yes |
| Analog Outputs | Yes |
| Discrete Inputs | Yes |
| Discrete Outputs | Yes |
| Input Details | 2 Isolated discrete and 8 Universal |
| Output Details | 2 Relay, 4 NMOS, 2 Analog |
| Intrinsically Safe | No |
| Max Temp Operating Conditions (C) | 60 |
| Lcd Display | Yes |
| Min Temp Operating Conditions (C) | -20 |
| Processing Speed (Mhz) | 100 |
| On Board Memory (Mb) | 2 |
| Dimension Length (Mm) | 150 |
| Application: Indicator Light | Yes |
| Ether Net/ I P | Yes |
| Modbus Rtu | Yes |
| Modbus/ T C P | Yes |
| P R O F I N E T | No |
| R S 232 | Yes |
| R S 485 | Yes |
| Wireless | No |
| 1 Wire Serial Interface | No |
| Cert: Australia/New Zealand | Yes |
| Cert: Korea | Yes |
| Cert: Brazil | Yes |
