Banner Engineering DES4-M51-F51-D
S4B CASCADE Custom to M12 Double-Ended
5-pin M12 Male Branch 400 mm, Black PVC Jacket (1)
5-pin M12 Female Branch 350 mm, Yellow PVC Jacket(1)
Nickel-Plated Bra…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
S4B CASCADE Custom to M12 Double-Ended
5-pin M12 Male Branch 400 mm, Black PVC Jacket (1)
5-pin M12 Female Branch 350 mm, Yellow PVC Jacket(1)
Nickel-Plated Brass Coupling Nut
FID2 or Higher
Specification
| Ip Rating | IP65 |
|---|---|
| Connector 1 Type | M12 |
| Connector 2 Type | M12 |
| Connector 1 Number Of Contacts | 5 |
| Coupling Nut Material | Nickel Plated Brass |
| Connector 2 Number Of Contacts | 5 |
| Cable Jacket Material | PVC |
| Cable Jacket Color | Black |
| Connector 1 Key Code | A |
| Connector 2 Key Code | A |
| Connector 1 Gender | Male |
| Outside Cable Diameter (Mm) | 5.6 |
| Connector 2 Gender | Female |
| Cordset Length (M) | 0.4 |
| Connector 1 Orientation | Straight |
| Connector 2 Orientation | Straight |
| Overmold Material And Color | PUR Black |
| Shield/No Shield | No Shield |
| Minimum Temp. (Celsius) | -40 |
| Trunk: Connector Type | S4B-Custom |
| Maximum Temp. (Celsius) | 70 |
| Current Rating (A) | 2.0 |
| Number Of Branches | 2 |
| Branches: Connector Types | M12, M12 |
| Branches: Number Of Contacts | 5, 5 |
| Branches: Genders | Male, Female |
| Branches: Orientations | Straight, Straight |
| Branches: Cable Jacket Material | PVC, PVC |
| Coiled | No |
| Wiring | Custom |
| Splitter: Overmold Material And Color | PUR Black |
| Supply Voltage | 60 V ac / 75 V dc |
| Item Status | RELEASED |
| Indication | No |
| Feature: Washdown Rated | No |
| Feature: Cascade | Yes |
| Oil/Grease Resistant | No |
| Eplan Status | Published |
| Eplan Original Sent Date | 05/07/2024 |
