Banner Engineering BR-M12F12F9-0.5
Receptacle 12-pin Female
12×24 PVC 0.5 m Length
Front Mount PG9 w/ Locknut
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Receptacle 12-pin Female
12×24 PVC 0.5 m Length
Front Mount PG9 w/ Locknut
Specification
| Ip Rating | IP67 |
|---|---|
| Connector 1 Type | M12 |
| Connector 2 Type | Flying Leads |
| Number Of Ends | Single Ended |
| Connector 1 Number Of Contacts | 12 |
| Coupling Nut Material | Nickel Plated Brass |
| Connector 1 Key Code | A |
| Connector 1 Gender | Female |
| Cordset Length (M) | 0.5 |
| Minimum Temp. (Celsius) | -40 |
| Maximum Temp. (Celsius) | 70 |
| Current Rating (A) | 1.5 |
| Supply Voltage | 30 V ac/dc |
| Item Status | RELEASED |
| Indication | No |
| Feature: Washdown Rated | No |
| Feature: Hazardous Area | No |
| Oil/Grease Resistant | No |
