Sick YG2A15-C50S01MMLB3
Connectors and cables | Sensor-actuator cables | YG2A15-C50S01MMLB3 | Connection type head A: Female connector, M12, 2-pin, angled, A-coded | Connection type head B: Female connector, Molex, straight…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Connectors and cables | Sensor-actuator cables | YG2A15-C50S01MMLB3 | Connection type head A: Female connector, M12, 2-pin, angled, A-coded | Connection type head B: Female connector, Molex, straight | Signal type: Sensor/actuator cable | Cable: PVC | Description: Sensor/actuator cable, unshielded
Specification
Technical specifications
| Connection type head A | Female connector, M12, 2-pin, angled, A-coded |
|---|---|
| Connection type head B | Female connector, Molex, straight |
| Locking plug connector | Screw connection |
| Connector material | TPU |
| Connector color | Black |
| Locking nut material | Zinc die-cast, nickel-plated |
| Cable | PVC |
| Jacket material | PVC |
| Jacket color | Black |
| Conductor cross section | 0.34 mm² |
| Shielding | Unshielded |
| Rated impulse voltage | 1.5Â kV |
| Current loading | 4Â A |
| Signal type | Sensor/actuator cable |
| Enclosure rating | (M12) IP67 |
| Flexible use | –25 °C ... +80 °C |
| Stationary position | –40 °C ... +80 °C |
| Insulation resistance | 20 MΩ |
| Overvoltage category | III |
Certificates
| EU declaration of conformity | ✔ |
|---|---|
| UK declaration of conformity | ✔ |
| China RoHS | ✔ |
Classifications
| ECLASS 5.0 | 19030312 |
|---|---|
| ECLASS 5.1.4 | 19030312 |
| ECLASS 6.0 | 27060304 |
| ECLASS 6.2 | 27060304 |
| ECLASS 7.0 | 27060304 |
| ECLASS 8.0 | 27060304 |
| ECLASS 8.1 | 27060304 |
| ECLASS 9.0 | 27060304 |
| ECLASS 10.0 | 27060304 |
| ECLASS 11.0 | 27060304 |
| ECLASS 12.0 | 27060304 |
| ETIM 5.0 | EC000830 |
| ETIM 6.0 | EC000830 |
| ETIM 7.0 | EC003249 |
| ETIM 8.0 | EC003249 |
| UNSPSC 16.0901 | 26121604 |
