Photoelectric sensors | W2 | WTB2SC-2P3244A00 | Functional principle: Photoelectric proximity sensor | Functional principle detail: Background suppression | Switching output: PNP | Switching mode: Light/dark switching | Connection type: Cable with M8 male connector, 4-pin, 200 mm | Light source: PinPoint LED | Adjustment: IO-Link | Communication interface: IO-Link | Smart Sensor: Enhanced Sensing, efficient communication, Smart Task | Smart Task name: Base logics
Specification
Features
| Functional principle | Photoelectric proximity sensor |
|---|---|
| Functional principle detail | Background suppression |
| Dimensions (W x H x D) | 7.7 mm x 21.8 mm x 13.5 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 4 mm ... 110 mm 1) |
| Preset sensing range | 45Â mm |
| Sensing range | 10 mm ... 90 mm 1) |
| Type of light | Visible red light |
| Light source | PinPoint LEDÂ 2) |
| Light spot size (distance) | ÃÂ 4.4Â mm (60Â mm) |
| Wave length | 640Â nm |
| Adjustment | IO-Link |
| Pin 2Â configuration | External input, Teach-in input, Sender off input, Detection output, logic output |
| Special applications | Detecting small objects |
Mechanics/electronics
| Supply voltage UB | 10Â VÂ DCÂ ... 30Â VÂ DCÂ 1) |
|---|---|
| Ripple | < 5 Vpp 2) |
| Current consumption | 20Â mAÂ 3) |
| Switching output | PNPÂ 4)Â 5) |
| Switching mode | Light/dark switching 4) |
| Switching mode selector | Programmable |
| Output current Imax. | â¤Â 50 mA |
| Response time | < 0.5 ms 6) |
| Response time Q/ on Pin 2 | 300 µs ... 450 µs 6) 7) |
| Switching frequency | 1,000Â Hz |
| Switching frequency Q / to pin 2 | 1,000 Hz 7) 8) |
| Connection type | Cable with M8 male connector, 4-pin, 200 mm 9) |
| Cable material | Plastic, PVC |
| Conductor cross section | 0.09 mm² |
| Cable diameter | ÃÂ 3Â mm |
| Circuit protection | AÂ 10)BÂ 11)DÂ 12) |
| Protection class | III |
| Housing material | Plastic, ABS/PC |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP67 |
| Description | IO-Link |
| Ambient operating temperature | â25 °C ... +50 °C |
| Ambient temperature, storage | â40 °C ... +75 °C |
| UL File No. | NRKH.E181493 |
| Repeatability Q/ on Pin 2: | 150 µs 7) |
Safety-related parameters
| MTTFD | 1,547Â years |
|---|---|
| DCavg | 0Â % |
Communication interface
| Communication interface | IO-Link V1.1 |
|---|---|
| Communication Interface detail | COM2 (38,4Â kBaud) |
| Cycle time | 2.3Â ms |
| Process data length | 16Â Bit |
| Process data structure | Bit 0Â = switching signal QL1Bit 1Â = switching signal QL2Bit 2Â ... 15Â = empty |
| VendorID | 26 |
| DeviceID HEX | 0x800121 |
| DeviceID DEC | 8388897 |
Smart Task
| Smart Task name | Base logics |
|---|---|
| Logic function | DirectANDORWINDOWHysteresis |
| Timer function | DeactivatedSwitch-on delayOff delayON and OFF delayImpulse (one shot) |
| Inverter | Yes |
| Switching frequency | SIO Direct: 1000 Hz 1)SIO Logic: 1000 Hz 2)IOL: 900 Hz 3) |
| Response time | SIO Direct: 300 µs ... 450 µs 1)SIO Logic: 500 µs ... 600 µs 2)IOL: 500 µs ... 900 µs 3) |
| Repeatability | SIO Direct: 150 µs 1)SIO Logic: 150 µs 2)IOL: 400 µs 3) |
| Switching signal QL1 | Switching output |
| Switching signal QL2 | Switching output |
Diagnosis
| Device status | Yes |
|---|
Certificates
| EU declaration of conformity | â |
|---|---|
| ACMA declaration of conformity | â |
| Moroccan declaration of conformity | â |
| China RoHS | â |
| cULus certificate | â |
| IO-Link certificate | â |
| Photobiological safety (DIN EN 62471) certificate | â |
| Information according to Art. 3 of Data Act (Regulation EU 2023/2854) | â |
Classifications
| ECLASS 5.0 | 27270904 |
|---|---|
| ECLASS 5.1.4 | 27270904 |
| ECLASS 6.0 | 27270904 |
| ECLASS 6.2 | 27270904 |
| ECLASS 7.0 | 27270904 |
| ECLASS 8.0 | 27270904 |
| ECLASS 8.1 | 27270904 |
| ECLASS 9.0 | 27270904 |
| ECLASS 10.0 | 27270904 |
| ECLASS 11.0 | 27270904 |
| ECLASS 12.0 | 27270903 |
| ETIM 5.0 | EC002719 |
| ETIM 6.0 | EC002719 |
| ETIM 7.0 | EC002719 |
| ETIM 8.0 | EC002719 |
| UNSPSC 16.0901 | 39121528 |
