Sick WTB12-3N2411 - Image 1

Fast delivery within 72 Hours

Sick WTB12-3N2411

Photoelectric sensors | W12-3 | WTB12-3N2411 | Sensing range max.: 20 mm … 600 mm | Functional principle: Photoelectric proximity sensor | Functional principle detail: Background suppression | Switc…

Request for Quote

Add to compare
Add to wishlist

Shipping & Delivery

  • Courier delivery

Our courier will deliver to the specified address

5-6 Days

From €20

  • DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

From €40

  • Warranty 1 year

More details

  • Free 30-Day returns

More details

Description

Photoelectric sensors | W12-3 | WTB12-3N2411 | Sensing range max.: 20 mm … 600 mm | Functional principle: Photoelectric proximity sensor | Functional principle detail: Background suppression | Switching output: NPN | Switching mode: Light/dark switching | Connection type: Male connector M12, 4-pin | Light source: LED | Type of light: Infrared light | Adjustment: Potentiometer | Housing: Rectangular | Included with delivery: 2 x clamps BEF-KH-W12, incl. screws

Specification

Features

Functional principlePhotoelectric proximity sensor
Functional principle detailBackground suppression
Sensing range max.20 mm ... 600 mm 1)
Sensing range20 mm ... 600 mm
Light sourceLEDÂ 2)
Type of lightInfrared light
Light spot size (distance)15 mm x 15 mm (200 mm)
Wave length850Â nm
AdjustmentPotentiometer, 5Â turns
Items supplied2Â x clamps BEF-KH-W12, incl. screws

Safety-related parameters

MTTFD533Â years
DCavg0Â %
TM (mission time)20Â years

Electronics

Supply voltage UB10Â VÂ DCÂ ... 30Â VÂ DCÂ 1)
Ripple< 5 Vpp 2)
Current consumption55Â mAÂ 3)
Protection classIII
TypeNPN
Switching modeLight/dark switching
Signal voltage NPN HIGH/LOWApprox. VS / < 2.5Â V
Output current Imax.≤ 100 mA
Response time≤ 330 µs 4)
Switching frequency1,500 Hz 5)
Output functionComplementary
Circuit protectionAÂ 6)CÂ 7)DÂ 8)

Mechanics

HousingRectangular
Dimensions (W x H x D)15.6 mm x 48.5 mm x 42 mm
ConnectionMale connector M12, 4-pin
HousingMetal
Front screenPlastic, PMMA
Weight120Â g

Ambient data

Enclosure ratingIP66IP67IP69K
Ambient operating temperature–40 °C ... +60 °C
Ambient temperature, storage–40 °C ... +75 °C
UL File No.NRKH.E181493 & NRKH7.E181493

Certificates

EU declaration of conformity✔
UK declaration of conformity✔
ACMA declaration of conformity✔
Moroccan declaration of conformity✔
China RoHS✔
ECOLAB certificate✔
cULus certificate✔
Photobiological safety (DIN EN 62471) certificate✔

Classifications

ECLASS 5.027270904
ECLASS 5.1.427270904
ECLASS 6.027270904
ECLASS 6.227270904
ECLASS 7.027270904
ECLASS 8.027270904
ECLASS 8.127270904
ECLASS 9.027270904
ECLASS 10.027270904
ECLASS 11.027270904
ECLASS 12.027270903
ETIM 5.0EC002719
ETIM 6.0EC002719
ETIM 7.0EC002719
ETIM 8.0EC002719
UNSPSC 16.090139121528
