Sick WS/WE12L-2P430S01 - Image 1

Fast delivery within 72 Hours

Sick WS/WE12L-2P430S01

Photoelectric sensors | W12-2 Laser | WS/WE12L-2P430S01 | Sensing range max.: 0 m … 25 m | Functional principle: Through-beam photoelectric sensor | Switching output: PNP | Connection type: Male con…

Request for Quote

Add to compare
Add to wishlist

Shipping & Delivery

  • Courier delivery

Our courier will deliver to the specified address

5-6 Days

From €20

  • DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

From €40

  • Warranty 1 year

More details

  • Free 30-Day returns

More details

Description

Photoelectric sensors | W12-2 Laser | WS/WE12L-2P430S01 | Sensing range max.: 0 m … 25 m | Functional principle: Through-beam photoelectric sensor | Switching output: PNP | Connection type: Male connector M12, 4-pin | Light source: Laser | Type of light: Visible red light | Laser class: 2 | Adjustment: None | Special features: Reactivation delay: 0.5 s, Aperture 1mm in front of receiver | Housing: Rectangular

Specification

Features

Functional principleThrough-beam photoelectric sensor
Sensing range max.0 m ... 25 m
Light sourceLaser 1)
Type of lightVisible red light
Normative referenceENÂ 60825-1:2014, IECÂ 60825-1:2007
Laser class2Â 2)Â 3)
Wave length650Â nm
AdjustmentNone
Special featuresReactivation delay: 0.5Â sAperture 1mm in front of receiver
Special applicationsDetecting small objects, Detection of objects moving at high speeds
Part number of individual components2030011Â WE12L-2P430S01 2030012Â WS12L-2D430S01

Electronics

Supply voltage UB10Â VÂ DCÂ ... 30Â VÂ DCÂ 1)
Ripple< 5 Vpp 2)
Current consumption, sender≤ 45 mA 3)
Current consumption, receiver≤ 15 mA 3)
Protection classIII
TypePNP
Output current Imax.≤ 100 mA
Response time≤ 200 µs 4)
Switching frequency2,500 Hz 5)
Circuit protectionAÂ 6)CÂ 7)DÂ 8)

Mechanics

HousingRectangular
Dimensions (W x H x D)15 mm x 49 mm x 41.5 mm
ConnectionMale connector M12, 4-pin
HousingMetal
Front screenPlastic, PMMA
Weight260Â g

Ambient data

Enclosure ratingIP67IP69K
Ambient operating temperature–10 °C ... +50 °C
Ambient temperature, storage–25 °C ... +75 °C

Certificates

EU declaration of conformity✔
UK declaration of conformity✔
ACMA declaration of conformity✔
Moroccan declaration of conformity✔
China RoHS✔
cULus certificate✔
Laser safety (IEC 60825-1) certificate✔

Classifications

ECLASS 5.027270901
ECLASS 5.1.427270901
ECLASS 6.027270901
ECLASS 6.227270901
ECLASS 7.027270901
ECLASS 8.027270901
ECLASS 8.127270901
ECLASS 9.027270901
ECLASS 10.027270901
ECLASS 11.027270901
ECLASS 12.027270901
ETIM 5.0EC002716
ETIM 6.0EC002716
ETIM 7.0EC002716
ETIM 8.0EC002716
UNSPSC 16.090139121528
