Sick WL12G-3P2582S04
Photoelectric sensors | W12G | WL12G-3P2582S04 | Sensing range max.: 0 m … 4 m | Functional principle: Photoelectric retro-reflective sensor | Switching output: PNP | Switching mode: Light switching…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Photoelectric sensors | W12G | WL12G-3P2582S04 | Sensing range max.: 0 m … 4 m | Functional principle: Photoelectric retro-reflective sensor | Switching output: PNP | Switching mode: Light switching | Connection type: Plug, M12, 5-pin | Light source: LED | Type of light: Infrared light | Housing material: Zinc diecast | Adjustment: Wire/pin, Teach-in button | Special features: Different functions selectable by teach-in. Function 1 = Sensitivity adjustment. Function 2 = Operation mode selection (Mode I = 40 %, Mode II = 18 %, Mode III = 10 %). Function 3 = change pin 4 and pin 2 assignments | Housing: Rectangular | Included with delivery: Further details can be found in the operating instructions 8015091
Specification
Features
| Functional principle | Photoelectric retro-reflective sensor |
|---|---|
| Sensing range max. | 0 m ... 4 m 1) |
| Polarisation filter | Yes |
| Light source | LEDÂ 2) |
| Type of light | Infrared light |
| Light spot size (distance) | ÃÂ 25Â mm (1.5Â m) |
| Wave length | 850Â nm |
| Adjustment | Cable, Single teach-in button |
| Special features | Different functions selectable by teach-in. Function 1Â = Sensitivity adjustment. Function 2Â = Operation mode selection (Mode IÂ = 40Â %, Mode IIÂ = 18Â %, Mode IIIÂ = 10Â %). Function 3Â = change pin 4Â and pin 2Â assignments |
| Special applications | Detecting transparent objects |
| Items supplied | Further details can be found in the operating instructions 8015091 |
Electronics
| Supply voltage UB | 10Â VÂ DCÂ ... 30Â VÂ DCÂ 1) |
|---|---|
| Ripple | < 5 Vpp 2) |
| Current consumption | 40Â mAÂ 3) |
| Protection class | III |
| Type | PNPÂ 4) |
| Switching mode | Light switching 4) |
| Signal voltage PNP HIGH/LOW | Approx. VS â 2.5Â V / 0Â V |
| Output current Imax. | â¤Â 100 mA |
| Response time | â¤Â 600 µs 5) |
| Switching frequency | 1,500 Hz 6) |
| Circuit protection | AÂ 7)BCÂ 8)DÂ 9) |
| Special feature | Detecting transparent objects |
| Operating mode | Mode I, 40Â % attenuation, Mode II, 18Â % attenuation, Mode III, 10Â % attenuation |
Mechanics
| Housing | Rectangular |
|---|---|
| Dimensions (W x H x D) | 15.5 mm x 48.5 mm x 42 mm |
| Connection | Plug, M12, 5-pin |
| Housing | Metal, zinc diecast |
| Front screen | Plastic, PMMA |
| Weight | 120Â g |
Ambient data
| Enclosure rating | IP66IP67 |
|---|---|
| Ambient operating temperature | â40 °C ... +60 °C |
| Ambient temperature, storage | â40 °C ... +75 °C |
| UL File No. | NRKH.E181493 & NRKH7.E181493 |
Certificates
| EU declaration of conformity | â |
|---|---|
| UK declaration of conformity | â |
| ACMA declaration of conformity | â |
| Moroccan declaration of conformity | â |
| China RoHS | â |
| ECOLAB certificate | â |
| cULus certificate | â |
| Photobiological safety (DIN EN 62471) certificate | â |
Classifications
| ECLASS 5.0 | 27270902 |
|---|---|
| ECLASS 5.1.4 | 27270902 |
| ECLASS 6.0 | 27270902 |
| ECLASS 6.2 | 27270902 |
| ECLASS 7.0 | 27270902 |
| ECLASS 8.0 | 27270902 |
| ECLASS 8.1 | 27270902 |
| ECLASS 9.0 | 27270902 |
| ECLASS 10.0 | 27270902 |
| ECLASS 11.0 | 27270902 |
| ECLASS 12.0 | 27270902 |
| ETIM 5.0 | EC002717 |
| ETIM 6.0 | EC002717 |
| ETIM 7.0 | EC002717 |
| ETIM 8.0 | EC002717 |
| UNSPSC 16.0901 | 39121528 |
