Fast delivery within 72 Hours
Sick WIB A-2041
Network devices | IO-Link Wireless Gateway | WIB A-2041 | Product category: IO-Link Wireless | Communication interface: IO-Link | Scope of delivery: WIB A-2041 | Further functions: Initial setup, conf…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Network devices | IO-Link Wireless Gateway | WIB A-2041 | Product category: IO-Link Wireless | Communication interface: IO-Link | Scope of delivery: WIB A-2041 | Further functions: Initial setup, configuration and monitoring using WIE, via an internal Web Server interface or by a PLC to WIM
Specification
Features
| Product category | IO-Link Wireless |
|---|---|
| Further functions | Initial setup, configuration and monitoring using WIE, via an internal Web Server interface or by a PLC to WIM |
| Items supplied | WIB A-2041 |
| Radio class | 1Â SMA antennaUnlicensed 2.4GHz ISM bandTx power 10Â dBm maxRx Sensitivity PER 30% @ â92 dBm or better |
Mechanics/electronics
| Power | Power In: M12 ports, 5-pin, A-coded |
|---|---|
| IO-Link or DI/DO Ports | M12 ports, 5-pin, A-coded |
| Supply voltage | 18Â VÂ ... 32Â V, 24Â VÂ DC |
| Current carrying capacity (PWR1, PWR2) max. | Max. 1 A |
| Current consumption | Typ. 26 mA |
| Number | 2, configurable |
| Number | 2, configurable |
| Optical indicators | LEDs (IO-Link Wireless Status, power supply) |
| Enclosure rating | IP67 |
| Housing material | Lightweight plastic |
| Housing color | Dark gray |
| Dimensions (L x W x H) | 80 mm x 48 mm x 15 mm |
Communication interface
| Communication interface | IO-Link |
|---|
Ambient data
| Ambient operating temperature | â25 °C ... +60 °C 1) |
|---|---|
| Electromagnetic compatibility (EMC) | ENÂ 301489-1 V2.2.3Â 2019 |
Certificates
| EU declaration of conformity | â |
|---|---|
| UK declaration of conformity | â |
| IO-Link certificate | â |
Classifications
| ECLASS 5.0 | 27242208 |
|---|---|
| ECLASS 5.1.4 | 27242608 |
| ECLASS 6.0 | 27242608 |
| ECLASS 6.2 | 27242608 |
| ECLASS 7.0 | 27242608 |
| ECLASS 8.0 | 27242608 |
| ECLASS 8.1 | 27242608 |
| ECLASS 9.0 | 27242608 |
| ECLASS 10.0 | 27242608 |
| ECLASS 11.0 | 27242608 |
| ECLASS 12.0 | 27242608 |
| ETIM 5.0 | EC001604 |
| ETIM 6.0 | EC001604 |
| ETIM 7.0 | EC001604 |
| ETIM 8.0 | EC001604 |
| UNSPSC 16.0901 | 32151705 |
