Sick THTE-1PA541506MZ
Temperature sensors | THTE | THTE-1PA541506MZ | Temperature measuring range: –50 °C … +150 °C | Process connection: Conical coupling (DIN 11851) DN 40 with union nut | Insertion length/diameter of p…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Temperature sensors | THTE | THTE-1PA541506MZ | Temperature measuring range: –50 °C … +150 °C | Process connection: Conical coupling (DIN 11851) DN 40 with union nut | Insertion length/diameter of probe: 150 mm / 6 mm | Seal: Without seal | Output signal: Pt100, 4-wire | Connection type: M12 round connector x 1, 4-pin | Enclosure rating: IP67, IP69 | Communication interface: –
Specification
Features
| Measuring range | â50 °C ... +150 °C |
|---|---|
| Sensor element | Pt100 |
| Output signal | Pt100, 4-wire |
Mechanics/electronics
| Communication interface | - |
|---|---|
| Process connection | Conical coupling (DINÂ 11851) DN 40Â with union nut |
| Seal | Without seal |
| Insertion length/diameter of probe | 150 mm / 6 mm |
| Wetted parts | Stainless steel 1.4435 / 316L, Ra ⤠0.8 µm |
| Maximum process pressure | ⤠40 bar 1) |
| Pressure resistance | Max. 40Â bar at room temperature |
| Housing material | Stainless steel (CrNi) |
| Connection type | M12 round connector x 1, 4-pin 2) |
| Enclosure rating | IP67Â 3)IP69Â 3) |
| Measuring current | 0.1Â mAÂ ... 1Â mA |
| Electrical safety | Protection class: III, dielectric strength: 500Â VÂ AC |
| Protection class III | â |
| Initialization time | Max. 4 s |
Performance
| Accuracy of sensor element | Class A according to IECÂ 60751Â 1) |
|---|---|
| Response time | t50 â¤Â 4.7 s 2)t90 â¤Â 12.2 s 2) |
Ambient data
| Ambient temperature | â40 °C ... +85 °C |
|---|---|
| Storage and transport temperature | â40 °C ... +85 °C |
| Shock resistance | 50Â g, 6ms (according to IECÂ 60068-2-27) |
| Relative humidity | ⤠100 % 1) |
Certificates
| China RoHS | â |
|---|
Classifications
| ECLASS 5.0 | 27200208 |
|---|---|
| ECLASS 5.1.4 | 27200208 |
| ECLASS 6.0 | 27200208 |
| ECLASS 6.2 | 27200208 |
| ECLASS 7.0 | 27200208 |
| ECLASS 8.0 | 27200208 |
| ECLASS 8.1 | 27200208 |
| ECLASS 9.0 | 27200208 |
| ECLASS 10.0 | 27200208 |
| ECLASS 11.0 | 27200208 |
| ECLASS 12.0 | 27200208 |
| ETIM 5.0 | EC002994 |
| ETIM 6.0 | EC002994 |
| ETIM 7.0 | EC002994 |
| ETIM 8.0 | EC002994 |
| UNSPSC 16.0901 | 41112211 |
