Sick STR1-SAXU0AC8
Safety switches | STR1 | STR1-SAXU0AC8 | Coding: Uniquely coded | Assured switch on distance Sao: 14 mm | Connection type Detail: Cable with plug M12, 8-pin | Length of cable: 0.2 m | Safe series conn…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Safety switches | STR1 | STR1-SAXU0AC8 | Coding: Uniquely coded | Assured switch on distance Sao: 14 mm | Connection type Detail: Cable with plug M12, 8-pin | Length of cable: 0.2 m | Safe series connection: With T-connector (without diagnostics), with Flexi Loop (with diagnostics) | Auxiliary contact (AUX): 1 (Switching behavior complementary to OSSDs)
Specification
Features
| System part | sensor |
|---|---|
| Sensor principle | RFID |
| Number of safe outputs | 2 |
| Auxiliary contact (AUX) | 1Â (Switching behavior complementary to OSSDs) |
| Assured switch on distance Sao | 14 mm (â10 ... +70 °C) 1)10 mm (â30 ... â10 °C) 1) |
| Assured switch off distance Sar | 28 mm 1) |
| Active sensor surfaces | 3 |
| Active sensor surface | Top, sides (left, right)Â 2) |
| Actuation directions | 5 |
| Coding | Uniquely coded |
Safety-related parameters
| Safety integrity level | SIL 3Â (IECÂ 61508) |
|---|---|
| Category | Category 4Â (ENÂ ISOÂ 13849) |
| Performance level | PL e (EN ISO 13849) |
| PFHD (mean probability of a dangerous failure per hour) | 5,21 x 10-9 |
| TM (mission time) | 20Â years (ENÂ ISOÂ 13849) |
| Type | Type 4Â (ENÂ ISOÂ 14119) |
| Actuator coding level | High coding level (ENÂ ISOÂ 14119) |
| Safe state in the event of a fault | At least one safety-related semiconductor output (OSSD) is in the OFF state. |
Functions
| Safe series connection | With T-connector (without diagnostics)With Flexi Loop (with diagnostics) |
|---|
Interfaces
| Connection type | Cable with plug M12, 8-pin |
|---|---|
| Length of cable | 0.2Â m |
| Long connecting cable | ⤠200 m |
| Cable diameter | 5.5Â mm |
| Conductor cross section | 0.12 mm² |
| Bend radius (with fixed installation) | > 8Â x cable diameter |
| Bend radius (with moving cable) | > 12Â x cable diameter |
| Cable material | PVC |
| Conductor material | Copper |
| Coupling nut material | Zinc die-cast, nickel-plated |
| Display elements | LEDs |
| Diagnostics indicator | â |
| Status display | â |
Electronics
| Protection class | III (IECÂ 61140) |
|---|---|
| Classification according to cULus | Class 2 |
| Supply voltage Vs | 24Â VÂ DC (19.2Â VÂ DCÂ ... 28.8Â VÂ DC) |
| Power consumption | 50Â mA |
| Type of output | Self-monitoring semiconductor outputs (OSSDs) |
| Output current | â¤Â 100 mA |
| Response time | 40 ms 1) |
| Release time | 100 ms 1) 2) |
| Risk time | 80 ms 1) 3) |
| Switch-on time | 2.5 s 4) |
Mechanics
| Dimensions (W x H x D) | 40 mm x 18 mm x 26 mm |
|---|---|
| Weight | 50Â g |
| Housing material | VISTAL® |
Ambient data
| Enclosure rating | IP67, IP69K (ENÂ 60529, ISOÂ 20653) |
|---|---|
| Ambient operating temperature | â30 °C ... +70 °C 1) |
| Storage temperature | â30 °C ... +70 °C |
| Vibration resistance | 10 Hz ... 55 Hz, 1 mm (IEC 60068-2-6) |
| Shock resistance | 30Â g, 11Â ms (IECÂ 60068-2-27) |
| EMC | ENÂ IECÂ 61326-3-1ENÂ IECÂ 60947-5-2ENÂ IECÂ 60947-5-3ENÂ 300330 V2.1.1 |
Classifications
| ECLASS 5.0 | 27272403 |
|---|---|
| ECLASS 5.1.4 | 27272403 |
| ECLASS 6.0 | 27272403 |
| ECLASS 6.2 | 27272403 |
| ECLASS 7.0 | 27272403 |
| ECLASS 8.0 | 27272403 |
| ECLASS 8.1 | 27272403 |
| ECLASS 9.0 | 27272403 |
| ECLASS 10.0 | 27272403 |
| ECLASS 11.0 | 27272403 |
| ECLASS 12.0 | 27274601 |
| ETIM 5.0 | EC001829 |
| ETIM 6.0 | EC001829 |
| ETIM 7.0 | EC001829 |
| ETIM 8.0 | EC001829 |
| UNSPSC 16.0901 | 39122205 |
Certificates
| EU declaration of conformity | â |
|---|---|
| UK declaration of conformity | â |
| ACMA declaration of conformity | â |
| China RoHS | â |
| cULus certificate | â |
| TÃV approval | â |
| TÃV approval annex | â |
| EC-Type-Examination approval | â |
