Sick SNL–08D12–KA10
Connectors and cables | Passive distribution boxes | SNL–08D12–KA10 | Number of slots: 8 | Slot connection type: M12, 5-pin, A-coded, female connector | Items supplied: With 4 dust covers and 10 attac…
Request for Quote
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
5-6 Days
From €20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From €40
-
Warranty 1 year
-
Free 30-Day returns
Description
Connectors and cables | Passive distribution boxes | SNL–08D12–KA10 | Number of slots: 8 | Slot connection type: M12, 5-pin, A-coded, female connector | Items supplied: With 4 dust covers and 10 attachable labels | Cable: 10 m, 19-wire, PVC | Note: Consolidation of sensor and actuator signals
Specification
Technical specifications
| Switching output | PNP |
|---|---|
| Number of slots | 8 |
| Slot connection type | M12, 5-pin, A-coded, female connector |
| Root port connection type | Flying leads |
| Connecting cable | 10Â m, 19-wire, PVC |
| Cable color | Black |
| Conductor cross section | 3 x 1.00 mm² + 16 x 0.50 mm² |
| Slots | 0.5Â Nm |
| Reference voltage | â¤Â 32 V |
| Current loading | â¤Â 11 A |
| Enclosure rating | IP67/ IP69K |
| Items supplied | With 4Â dust covers and 10Â attachable labels |
Classifications
| ECLASS 5.0 | 27279201 |
|---|---|
| ECLASS 5.1.4 | 27279201 |
| ECLASS 6.0 | 27279201 |
| ECLASS 6.2 | 27279201 |
| ECLASS 7.0 | 27279201 |
| ECLASS 8.0 | 27279201 |
| ECLASS 8.1 | 27279201 |
| ECLASS 9.0 | 27440108 |
| ECLASS 10.0 | 27440108 |
| ECLASS 11.0 | 27440108 |
| ECLASS 12.0 | 27440108 |
| ETIM 5.0 | EC002585 |
| ETIM 6.0 | EC002585 |
| ETIM 7.0 | EC002585 |
| ETIM 8.0 | EC002585 |
| UNSPSC 16.0901 | 31163032 |
